Ethernet AVB Endpoint User Guide www.xilinx.com 147
UG492 September 21, 2010
Directory and File Contents
implement/results
The results directory is created by the implement script, after which the implement script
results are placed in the results directory.
/simulation
The simulation directory and subdirectories that provide the files necessary to test a
Verilog or VHDL implementation of the example design. For more information, see
“Example Design,” page 152 .
simulation/functional
The functional directory contains functional simulation scripts provided with the core.
Table 15-6: Results Directory
Name Description
//implement/results
routed.v[hd] Back-annotated SimPrim-based model used
for timing simulation.
routed.sdf Timing information for simulation.
Back to Top
Table 15-7: Simulation Directory
Name Description
//simulation
demo_tb.v[hd] The demonstration test bench for the example
design. Instantiates the example design (the
Device Under Test (DUT)), generates clocks,
resets, and gathers statistics as the simulation
is run.
Back to Top
Table 15-8: Functional Directory
Name Description
//simulation/functional
simulate_mti.do ModelSim macro file that compiles Verilog or
VHDL sources and runs the functional
simulation to completion.
wave_mti.do ModelSim macro file that opens a wave
window and adds signals of interest to it. It is
called by the simulate_mti.do macro file.
simulate_ncsim.sh IES script file that compiles the Verilog or
VHDL sources and runs the functional
simulation to completion.
