Yamaha EX5 EN User Manual
Page 51
51
1
00 - 01
Mono Mode
1
00 - FF
Detune
1
00 - 7F
Volume
1
00 - 7F
PAN
1
00 - 7F
Chorus Send
1
00 - 7F
Reverb Send
1
00 - 7F
Vibrato Rate
1
00 - 7F
Vibrato Depth
1
00 - 7F
Vibrato Delay
1
00 - 7F
Filter Cut Off Frequency
1
00 - 7F
Filter Resonance
1
00 - 7F
EG Attack Time
1
00 - 7F
EG Decay Time
1
00 - 7F
EG Release Time
1
00 - 01
Portament Switch
1
00 - 7F
Portament Time
1
00 - 7F
Pitch EG Initial Level
1
00 - 7F
Pitch EG Attack Time
1
00 - 7F
Pitch EG Release Level
1
00 - 7F
Pitch EG Release Time
NET SIZE
132
GROSS SIZE
152
< Table 9 >
Current Performance / Part Bulk
Address
Size
Data
Parameter
Description
(H)
(H)
(H)
3p
00
00
1
00 - 7F
Bank Select MSB
1
00 - 02
Bank Select LSB
1
00 - 7F
Program Number
1
00 - 0F
ASGN/TG Bank/MonoPoly
1
00 - FF
Detune
1
00 - 7F
Volume
1
00 - 7F
PAN
1
00 - 7F
Chorus Send
1
00 - 7F
Reverb Send
1
00 - 7F
Vibrato Rate
1
00 - 7F
Vibrato Depth
1
00 - 7F
Vibrato Delay
1
00 - 7F
Filter Cut Off Frequency
1
00 - 7F
Filter Resonance
1
00 - 7F
EG Attack Time
1
00 - 7F
EG Decay Time
1
00 - 7F
EG Release Time
1
00 - 33
INS SW/ARP SW/Portamento Mode/Portamento SW
1
00 - 7F
Portament Time
1
00 - 7F
Pitch EG Initial Level
1
00 - 7F
Pitch EG Attack Time
1
00 - 7F
Pitch EG Release Level
1
00 - 7F
Pitch EG Release Time
1
00 - 7F
TG Program Number
74
reserve
1
10 - 58
Pitch Bend Upper Depth
1
10 - 58
Pitch Bend Lower Depth
1
00 - 09
Output Select
1
00 - 7F
Layer SW/Rx ON/MIDI Channel
1
28 - 58
Transpose
1
00 - 7F
Note Limit Low
1
00 - 7F
Note Limit High
1
01 - 7F
Velocity Limit LOW
1
01 - 7F
Velocity Limit HIGH
1
00 - 7F
Tx MIDI A ON/Tx MIDI B ON/Master Keyboard Velocity Curve
1
00 - 7F
Master Keyboard Velocity Sense Depth
1
00 - 7F
Master Keyboard Velocity Sence OFFset
1
00 - 7F
Bend Wheel Initial Value
1
00 - 7F
Modulation Wheel1 Initial Value
1
00 - 7F
CH After Initial Value
1
00 - 7F
Modulation Wheel2 Initial Value
1
00 - 7F
Foot Controller Initial Value
1
00 - 7F
Breath Controller Initial Value
1
00 - 7F
Ribbon Controller Initial Value
1
00 - 7F
Knob1 Initial Value
1
00 - 7F
Init On/Knob2 Initial Value
1
00 - 7F
Knob3 Initial Value
1
00 - 7F
Knob4 Initial Value
1
00 - 7F
Knob5 Initial Value
1
00 - 7F
Knob6 Initial Value
1
00 - FF
Tx FV/PB/MOD1/CAT/MOD2/FC/BC/RB
1
00 - FF
Tx SUS/FS/KN1/KN2/KN3/KN4/KN5/KN6
1
00 - 3F
Init Tx CC/Tx Knob/Tx PC/Tx Vol&PAN/Tg CC/Tg Knob
p = Part No.(0 - F : Part1 - Part16)
NET SIZE
126
GROSS SIZE
144
< Table 10 >
Performance Bulk
Address
Size
Data
Parameter
Description
(H)
(H)
(H)
11
00
nn
Conforms to
nn = Memory No.(00 - 7F : Performance1 - Performance128)
NET SIZE
2148
GROSS SIZE
2456
< Table 11 >
Current Voice / All Bulk
Address
Size
Data
Parameter
Description
(H)
(H)
(H)
40
00
00
12
Voice Name
ASCII
1
00 - 7F
Category
1
00 - 7F
Voice Volume
1
00 - 80
Drum Layer Count/Layer Flag
1
00 - 7F
Velocity Sense Depth
1
00 - 7F
Velocity Sense Offset
1
00 - 7F
Reverb Send Level
1
00 - 7F
Chorus Send Level
1
00 - 7F
Reverb Type
1
00 - 7F
Reverb Parameter1
1
00 - 7F
Reverb Parameter2
1
00 - 7F
Reverb Parameter3
1
00 - 7F
Reverb Parameter4
1
00 - 7F
Reverb Parameter5
1
00 - 7F
Reverb Parameter6
1
00 - 7F
Reverb Parameter7
1
00 - 7F
Reverb Parameter8
1
00 - 7F
Reverb Parameter9
1
00 - 7F
Reverb Parameter10
1
00 - 7F
Reverb Parameter11
1
00 - 7F
Reverb Parameter12
2
00 00 - FF FF
Reverb Parameter13
2
00 00 - FF FF
Reverb Parameter14
1
00 - 7F
Reverb Return
1
00 - 7F
Reverb PAN
1
reserve
1
00 - 7F
Chorus Type
2
00 00 - FF FF
Chorus Parameter1
2
00 00 - FF FF
Chorus Parameter2
2
00 00 - FF FF
Chorus Parameter3
2
00 00 - FF FF
Chorus Parameter4
1
00 - 7F
Chorus Parameter5
1
00 - 7F
Chorus Parameter6
1
00 - 7F
Chorus Parameter7
1
00 - 7F
Chorus Parameter8
1
00 - 7F
Chorus Parameter9
1
00 - 7F
Chorus Parameter10
1
00 - 7F
Chorus Parameter11
1
00 - 7F
Chorus Parameter12
1
00 - 7F
Chorus Return
1
00 - 7F
Chorus PAN
1
00 - 7F
Send Chorus to Reverb
1
00 - 06
Ins Type/Voice Type
1
00 - 7F
Insertion-S Type
1
00 - 7F
Insertion-S Parameter1
1
00 - 7F
Insertion-S Parameter2
1
00 - 7F
Insertion-S Parameter3
1
00 - 7F
Insertion-S Parameter4
1
00 - 7F
Insertion-S Parameter5
1
00 - 7F
Insertion-S Parameter6
1
00 - 7F
Insertion-S Parameter7
1
00 - 7F
Insertion-S Parameter8
1
00 - 7F
Insertion-S Parameter9
1
00 - 7F
Insertion-S Parameter10
1
00 - 7F
Insertion-S Parameter11
1
00 - 7F
Insertion-S Parameter12
1
00 - 7F
Insertion-S Parameter13
1
00 - 7F
Insertion-S Parameter14
1
00 - 7F
Insertion-S Parameter15
1
00 - 7F
FDSP PAN
1
00 - 7F
Insertion-L Type
2
00 00 - FF FF
Insertion-L Parameter1
2
00 00 - FF FF
Insertion-L Parameter2
2
00 00 - FF FF
Insertion-L Parameter3
2
00 00 - FF FF
Insertion-L Parameter4
2
00 00 - FF FF
Insertion-L Parameter5
2
00 00 - FF FF
Insertion-L Parameter6
2
00 00 - FF FF
Insertion-L Parameter7
2
00 00 - FF FF
Insertion-L Parameter8
2
00 00 - FF FF
Insertion-L Parameter9
2
00 00 - FF FF
Insertion-L Parameter10
2
00 00 - FF FF
Insertion-L Parameter11
2
00 00 - FF FF
Insertion-L Parameter12
2
00 00 - FF FF
Insertion-L Parameter13
2
00 00 - FF FF
Insertion-L Parameter14
2
00 00 - FF FF
Insertion-L Parameter15
2
00 00 - FF FF
Insertion-L Parameter16
1
00 - 06
Arpeggiater Tempo Control
2
reserve
1
00 - 7F
Insertion To Reverb Send Level
1
00 - 7F
Insertion To Chorus Send Level
1
00 - FF
Insertion Large/Insertion Small/FDSP Type
20
FDSP Parameter
00 - 7F
1
00 - FF
Asgn/AN,VL Asgn/AWM Mono/AN,VL Mono/Port Mode/Port SW
1
00 - 7F
Portament Time
2
00 00 - FF FF
Bend Wheel Assign Switch
2
00 00 - FF FF
Modulation Wheel Assign Switch
2
00 00 - FF FF
CH After Assign Switch
2
00 00 - FF FF
Modulation Wheel 2 Assign Switch
2
00 00 - FF FF
Foot Controller Assign Switch
2
00 00 - FF FF
Breath Controller Assign Switch
2
00 00 - FF FF
Ribbon Controller Assign Switch
2
00 00 - FF FF
Knob1 Assign Switch
2
00 00 - FF FF
Knob2 Assign Switch
2
00 00 - FF FF
Knob3 Assign Switch
2
00 00 - FF FF
Knob4 Assign Switch
2
00 00 - FF FF
Knob5 Assign Switch
2
00 00 - FF FF
Knob6 Assign Switch
16
VC1~16 Control Depth
00 - 7F
16
VC1~16 Destination Assign Number
00 - FF
16
VC1~16 Dest Assign Elem
00 - 0F
1
10 - 58
Pitch Bend Upper Depth
