Midi data table – Yamaha EX5 EN User Manual
Page 45
45
MIDI Data Table
< Table 1 >
Current Performance / Common Parameter
Address
Size
Data
Parameter
Description
(H)
(H)
(H)
10
00
00
2
00 20 - 00 7F
Performance Name 1
00
01
2
00 20 - 00 7F
Performance Name 2
00
02
2
00 20 - 00 7F
Performance Name 3
00
03
2
00 20 - 00 7F
Performance Name 4
00
04
2
00 20 - 00 7F
Performance Name 5
00
05
2
00 20 - 00 7F
Performance Name 6
00
06
2
00 20 - 00 7F
Performance Name 7
00
07
2
00 20 - 00 7F
Performance Name 8
00
08
2
00 20 - 00 7F
Performance Name 9
00
09
2
00 20 - 00 7F
Performance Name 10
00
0A
2
00 20 - 00 7F
Performance Name 11
00
0B
2
00 20 - 00 7F
Performance Name 12
00
0C
2
00 00 - 00 7F
Category
00
0D
2
00 00 - 00 7F
Total Volume
00
0E
2
00 00 - 00 01
TG/Master KBD Mode
Master KBD,TG
00
0F
2
00 00 - 00 7F
Reverb Type
00
10
2
00 00 - 00 7F
Reverb Parameter1
00
11
2
00 00 - 00 7F
Reverb Parameter2
00
12
2
00 00 - 00 7F
Reverb Parameter3
00
13
2
00 00 - 00 7F
Reverb Parameter4
00
14
2
00 00 - 00 7F
Reverb Parameter5
00
15
2
00 00 - 00 7F
Reverb Parameter6
00
16
2
00 00 - 00 7F
Reverb Parameter7
00
17
2
00 00 - 00 7F
Reverb Parameter8
00
18
2
00 00 - 00 7F
Reverb Parameter9
00
19
2
00 00 - 00 7F
Reverb Parameter10
00
1A
2
00 00 - 00 7F
Reverb Parameter11
00
1B
2
00 00 - 00 7F
Reverb Parameter12
00
1C
2
00 00 - 01 7F
Reverb Parameter13H
00
1D
2
00 00 - 01 7F
Reverb Parameter13L
00
1E
2
00 00 - 01 7F
Reverb Parameter14H
00
1F
2
00 00 - 01 7F
Reverb Parameter14L
00
20
2
00 00 - 00 7F
Reverb Return
00
21
2
00 00 - 00 7F
Reverb PAN
00
22
2
reserve
00
23
2
00 00 - 00 7F
Chorus Type
00
24
2
00 00 - 01 7F
Chorus Parameter1H
00
25
2
00 00 - 01 7F
Chorus Parameter1L
00
26
2
00 00 - 01 7F
Chorus Parameter2H
00
27
2
00 00 - 01 7F
Chorus Parameter2L
00
28
2
00 00 - 01 7F
Chorus Parameter3H
00
29
2
00 00 - 01 7F
Chorus Parameter3L
00
2A
2
00 00 - 00 7F
Chorus Parameter4H
00
2B
2
00 00 - 00 7F
Chorus Parameter4L
00
2C
2
00 00 - 00 7F
Chorus Parameter5
00
2D
2
00 00 - 00 7F
Chorus Parameter6
00
2E
2
00 00 - 00 7F
Chorus Parameter7
00
2F
2
00 00 - 00 7F
Chorus Parameter8
00
30
2
00 00 - 00 7F
Chorus Parameter9
00
31
2
00 00 - 00 7F
Chorus Parameter10
00
32
2
00 00 - 00 7F
Chorus Parameter11
00
33
2
00 00 - 00 7F
Chorus Parameter12
00
34
2
00 00 - 00 7F
Chorus Return
00
35
2
00 00 - 00 7F
Chorus PAN
00
36
2
00 00 - 00 7F
Send Chorus to Reverb
00
37
2
00 00 - 00 06
Arpeggiater Tempo Control
off,Knob1...Knob6
00
38
2
reserve
00
39
2
reserve
00
3A
2
reserve
00
3B
2
00 00 - 00 0F
Bend Wheel Depth
00
3C
2
00 00 - 00 0F
Bend Wheel Curve
00
3D
2
00 00 - 00 7F
Bend Wheel Offset
00
3E
2
00 00 - 00 0F
Modulation Wheel1 Depth
00
3F
2
00 00 - 00 0F
Modulation Wheel1 Curve
00
40
2
00 00 - 00 7F
Modulation Wheel1 Offset
00
41
2
00 00 - 00 0F
CH After Depth
00
42
2
00 00 - 00 0F
CH After Curve
00
43
2
00 00 - 00 7F
CH After Offset
00
44
2
00 00 - 00 7F
Modulation Wheel2 CC Number
00
45
2
00 00 - 00 0F
Modulation Wheel2 Depth
00
46
2
00 00 - 00 0F
Modulation Wheel2 Curve
00
47
2
00 00 - 00 7F
Modulation Wheel2 Offset
00
48
2
00 00 - 00 7F
Foot Controller CC Number
00
49
2
00 00 - 00 0F
Foot Controller Depth
00
4A
2
00 00 - 00 0F
Foot Controller Curve
00
4B
2
00 00 - 00 7F
Foot Controller Offset
00
4C
2
00 00 - 00 7F
Breath Controller CC Number
00
4D
2
00 00 - 00 0F
Breath Controller Depth
00
4E
2
00 00 - 00 0F
Breath Controller Curve
00
4F
2
00 00 - 00 7F
Breath Controller Offset
00
50
2
00 00 - 00 7F
Ribbon Controller CC Number
00
51
2
00 00 - 00 0F
Ribbon Controller Depth
00
52
2
00 00 - 00 0F
Ribbon Controller Curve
00
53
2
00 00 - 00 0F
Ribbon Controller Hold
RESET,HOLD
00
54
2
00 00 - 00 7F
Ribbon Controller Offset
00
55
2
00 00 - 00 7F
Knob1 CC Number
00
56
2
00 00 - 00 0F
Knob1 Depth
00
57
2
00 00 - 00 0F
Knob1 Curve
00
58
2
00 00 - 00 7F
Knob1 Offset
00
59
2
00 00 - 00 7F
Knob2 CC Number
00
5A
2
00 00 - 00 0F
Knob2 Depth
00
5B
2
00 00 - 00 0F
Knob2 Curve
00
5C
2
00 00 - 00 7F
Knob2 Offset
00
5D
2
00 00 - 00 7F
Knob3 CC Number
00
5E
2
00 00 - 00 0F
Knob3 Depth
00
5F
2
00 00 - 00 0F
Knob3 Curve
00
60
2
00 00 - 00 7F
Knob3 Offset
00
61
2
00 00 - 00 7F
Knob4 CC Number
00
62
2
00 00 - 00 0F
Knob4 Depth
00
63
2
00 00 - 00 0F
Knob4 Curve
00
64
2
00 00 - 00 7F
Knob4 Offset
00
65
2
00 00 - 00 7F
Knob5 CC Number
00
66
2
00 00 - 00 0F
Knob5 Depth
00
67
2
00 00 - 00 0F
Knob5 Curve
00
68
2
00 00 - 00 7F
Knob5 Offset
00
69
2
00 00 - 00 7F
Knob6 CC Number
00
6A
2
00 00 - 00 0F
Knob6 Depth
00
6B
2
00 00 - 00 0F
Knob6 Curve
00
6C
2
00 00 - 00 7F
Knob6 Offset
00
6D
2
00 00 - 00 01
Arpeggiater On
OFF/ON
00
6E
2
00 00 - 00 7F
Arpeggiater Type
00
6F
2
00 00 - 00 01
Arpeggiater Hold
OFF/ON
00
70
2
00 00 - 00 01
Arpeggiater Tx A On
OFF/ON
00
71
2
00 00 - 00 01
Arpeggiater Tx B On
OFF/ON
00
72
2
00 00 - 00 0F
Arpeggiater MIDI Channel
00
73
2
00 00 - 00 7F
Note Limit Low
00
74
2
00 00 - 00 7F
Note Limit High
00
75
2
00 00 - 01 7F
Arpeggiater Tempo
00
76
2
00 00 - 00 7F
Knob1 Scene1
00
77
2
00 00 - 00 7F
Knob1 Scene2
00
78
2
00 00 - 00 7F
Knob2 Scene1
00
79
2
00 00 - 00 7F
Knob2 Scene2
00
7A
2
00 00 - 00 7F
Knob3 Scene1
00
7B
2
00 00 - 00 7F
Knob3 Scene2
00
7C
2
00 00 - 00 7F
Knob4 Scene1
00
7D
2
00 00 - 00 7F
Knob4 Scene2
00
7E
2
00 00 - 00 7F
Knob5 Scene1
00
7F
2
00 00 - 00 7F
Knob5 Scene2
01
00
2
00 00 - 00 7F
Knob6 Scene1
01
01
2
00 00 - 00 7F
Knob6 Scene2
01
02
2
00 00 - 00 01
Mono Mode
MONO,POLY
01
03
2
00 00 - 01 7F
Detune
01
04
2
00 00 - 00 7F
Volume
01
05
2
00 00 - 00 7F
PAN
01
06
2
00 00 - 00 7F
Chorus Send
01
07
2
00 00 - 00 7F
Reverb Send
01
08
2
00 00 - 00 7F
Vibrato Rate
01
09
2
00 00 - 00 7F
Vibrato Depth
01
0A
2
00 00 - 00 7F
Vibrato Delay
01
0B
2
00 00 - 00 7F
Filter Cut Off Frequency
01
0C
2
00 00 - 00 7F
Filter Resonance
01
0D
2
00 00 - 00 7F
EG Attack Time
01
0E
2
00 00 - 00 7F
EG Decay Time
01
0F
2
00 00 - 00 7F
EG Release Time
01
10
2
00 00 - 00 01
Portament Switch
01
11
2
00 00 - 00 7F
Portament Time
01
12
2
00 00 - 00 7F
Pitch EG Initial Level
01
13
2
00 00 - 00 7F
Pitch EG Attack Time
01
14
2
00 00 - 00 7F
Pitch EG Release Level
01
15
2
00 00 - 00 7F
Pitch EG Release Time
< Table 2 >
Current Performance / Part Parameter
Address
Size
Data
Parameter
Description
(H)
(H)
(H)
30
00
00
2
00 00 - 00 7F
Bank Select MSB
00
01
2
00 00 - 00 02
Bank Select LSB
00
02
2
00 00 - 00 7F
Program Number
00
03
2
00 00 - 00 01
Same Note Number Key ON Assign
00
04
2
00 00 - 00 03
TG Bank
00
05
2
00 00 - 00 01
MONO/POLY Mode
00
06
2
00 00 - 01 7F
Detune
00
07
2
00 00 - 00 7F
Volume
00
08
2
00 00 - 00 7F
PAN
00
09
2
00 00 - 00 7F
Chorus Send
00
0A
2
00 00 - 00 7F
Reverb Send
00
0B
2
00 00 - 00 7F
Vibrato Rate
00
0C
2
00 00 - 00 7F
Vibrato Depth
00
0D
2
00 00 - 00 7F
Vibrato Delay
00
0E
2
00 00 - 00 7F
Filter Cut Off Frequency
00
0F
2
00 00 - 00 7F
Filter Resonance
00
10
2
00 00 - 00 7F
EG Attack Time
00
11
2
00 00 - 00 7F
EG Decay Time
00
12
2
00 00 - 00 7F
EG Release Time
00
13
2
00 00 - 00 01
Insertion SW
00
14
2
00 00 - 00 01
Arpeggiater SW
00
15
2
00 00 - 00 01
Portament Mode
00
16
2
00 00 - 00 01
Portament SW
00
17
2
00 00 - 00 7F
Portament Time
00
18
2
00 00 - 00 7F
Pitch EG Initial Level
00
19
2
00 00 - 00 7F
Pitch EG Attack Time
00
1A
2
00 00 - 00 7F
Pitch EG Release Level
00
1B
2
00 00 - 00 7F
Pitch EG Release Time
00
1C
2
00 00 - 00 7F
TG Program Number
00
1D
2
reserve
|
|
00
66
2
reserve
00
67
2
00 10 - 00 58
Pitch Bend Upper Depth
00
68
2
00 10 - 00 58
Pitch Bend Lower Depth
00
69
2
00 00 - 00 09
Output Select
00
6A
2
00 00 - 00 01
Layer SW
00
6B
2
00 00 - 00 01
MIDI Receive SW
00
6C
2
reserve
00
6D
2
00 00 - 00 0F
MIDI Channel
00
6E
2
00 20 - 00 58
Transpose
00
6F
2
00 00 - 00 7F
Note Limit Low
00
70
2
00 00 - 00 7F
Note Limit High
00
71
2
00 01 - 00 7F
Velocity Limit LOW
00
72
2
00 01 - 00 7F
Velocity Limit HIGH
00
73
2
00 00 - 00 01
TX MIDI A
OFF/ON
