16
Internal 1-4 (1-64)
MSB=63
LSB=2
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
1 A1 Natural Grnd Pf AWM 024:3Band EQ 058:3Band EQ 002:Rev Hall 2 001:Chorus 1 off COM Cho Send off AWM FEG Depth off off AWM Pitch
2 A2 Chorus Bell Pf FDSP 023:EQ 055:Ensemble Detune 001:Rev Hall 1 004:Chorus 4 off InsL D/W Bal off AWM DCF Freq off off AWM Pitch
3 A3 Soulful Pf FDSP 024:3Band EQ 021:Auto Pan 001:Rev Hall 1 004:Chorus 4 off InsL LFO Freq off InsL L/R Depth off off AWM Pitch
4 A4 Ring Road Pf FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 AMD off AWM DCF Freq off off AWM DCF Freq
5 A5 JazzyBallad Or AWM 016:AMP Simulator 019:Rotary Speaker 2 001:Rev Hall 1 003:Chorus 3 off
InsL Rotor,AWM Volume,
InsS LPF Cutoff
off InsL L/H Bal off off
InsL Rotor,AWM Volume,
InsS LPF Cutoff
6 A6 Fullx4 Or AWM 001:Chorus 1 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off InsL LFO Freq,InsS LFO Freq off AWM DCF Freq off off InsL LFO Freq
7 A7 Hard Rock Or AWM 015:Overdrive 018:Rotary Speaker 1 001:Rev Hall 1 004:Chorus 4 off InsL LFO Freq off InsS D/W Bal off off AWM DCF Freq
8 A8 VintStrat Gt FDSP 016:AMP Simulator 020:Tremolo 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
9 A9 Strat 4-Way Gt AWM 024:3Band EQ 040:AMP Simulator 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
10 A10 Dist Lead Gt FDSP 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
11 A11 Flamenco Gt AWM 024:3Band EQ 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
12 A12 18 String Gt FDSP 023:EQ 043:Exciter 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
13 A13 Boogie Ba AN Layer 023:EQ 055:Ensemble Detune 009:Rev White Room 001:Chorus 1 off
AN VCO1 PMD,AN VCO2 PMD,
AWM LFO1 PMD
off AWM Volume off off AN Pitch
14 A14 Hardsequence Ba FDSP 016:AMP Simulator 015:Delay LR 001:Rev Hall 1 014:Phaser off FDSP Drive off InsS Drive off off FDSP Egde Bias
15 A15 StereoString St AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
16 A16 Veloci Ens St AWM 024:3Band EQ 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
17 B1 FunkySect Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 003:Chorus 3 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
18 B2 Smooth Brass Br AWM 000:THRU 058:3Band EQ 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
19 B3 Obersync Br FDSP 024:3Band EQ 017:Cross Delay 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
20 B4 Oberhorns Br AWM 000:THRU 017:Cross Delay 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
21 B5 Singleline Ld AWM 000:THRU 000:THRU 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM FEG Depth off off AWM Pitch
22 B6 New Drone Ld AN Layer 023:EQ 015:Delay LR 002:Rev Hall 2 004:Chorus 4 off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN Pitch
23 B7 Earth Lead Ld AN Layer 000:THRU 000:THRU 002:Rev Hall 2 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN VCF Freq
24 B8 Fusion Tekk Ld FDSP 000:THRU 014:Delay LCR 001:Rev Hall 1 015:Ensemble Detune off FDSP LFO Depth off InsL D/W Bal off off AWM DCF Freq
25 B9 Nightchoir En AWM 000:THRU 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
26 B10 Abendstern Pd FDSP 024:3Band EQ 017:Cross Delay 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
27 B11 Rising High Fx AWM 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
28 B12 VFEX Pd FDSP 020:Auto WAH 023:Phaser 1 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off FDSP Feedback off off AWM DCF Freq
29 B13 Silverlake Pd FDSP 017:Exciter 017:Cross Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
30 B14 Futopia Pd FDSP 000:THRU 055:Ensemble Detune 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
31 B15 AnalogSQ Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
32 B16 Equi 1998 Sq AN Layer 023:EQ 000:THRU 001:Rev Hall 1 016:Delay L,R off AN FEG DcyTim off AN VCF HPF off off AN Pitch
33 C1 4 by 4 Dr AWM 016:AMP Simulator 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Speed off COM Rev Send off off AWM DCF Freq
34 C2 4 Osc Sweep Fx AWM 000:THRU 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
35 C3 Countryman Sc FDSP 024:3Band EQ 063:V-Flanger 008:Rev Plate 016:Delay L,R off AWM LFO1 FMD off FDSP Pickup Pos. off off AWM DCF Freq
36 C4 Air Stabs Sc AN Poly 010:Flanger 2 017:Cross Delay 001:Rev Hall 1 006:Celeste 1 off AN VCF FMD off AN LFO1 Speed off off AN FEG Depth,AN Sync Depth
37 C5 AnalogSQ Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
38 C6 Art of Love Vo FDSP 017:Exciter 015:Delay LR 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
39 C7 Kick & Snare Dr AN Layer 024:3Band EQ 027:Gate Reverb 001:Rev Hall 1 016:Delay L,R off AN VCF FMD off AN VCF Freq off off AN Pitch
40 C8 Beades Se FDSP 000:THRU 021:Auto Pan 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off FDSP Pitch off off FDSP LFO Depth
41 C9 BigArpeggio Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
42 C10 Big Orch Co AWM 024:3Band EQ 054:Pitch Change 2 002:Rev Hall 2 015:Ensemble Detune off AWM LFO1 PMD,AWM LFO1 PMD off AWM Volume off off AWM DCF Freq
43 C11 Bip Sc AWM 022:Phaser 017:Cross Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM DCF Freq
44 C12 Blockhead Sc AWM 010:Flanger 2 040:AMP Simulator 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off InsS LFO Freq
45 C13 Blue Sc AWM 009:Flanger 1 017:Cross Delay 006:Rev Stage 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
46 C14 Brush 'Em Gt AWM 001:Chorus 1 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM AEG D2Tim off off AWM LFO1 PMD
47 C15 Clickbell Cp AWM 017:Exciter 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off InsS HPF Cutoff
48 C16 Cloud Nine Pd AWM 000:THRU 011:Flanger 2 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
49 D1 Adventure Fx FDSP 000:THRU 015:Delay LR 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
50 D2 Descender Fx AN Poly 000:THRU 011:Flanger 2 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off AN LFO1 Speed off off AN VCF Freq,AN VCF Reso
51 D3 Blue Lead Gt FDSP 016:AMP Simulator 000:THRU 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 PMD off InsS D/W Bal off off AWM LFO1 PMD
52 D4 DigiWorld Sq AWM 024:3Band EQ 053:Pitch Change 1 001:Rev Hall 1 016:Delay L,R off AWM LFO2Depth,AWM LFO2Speed off InsS EQ M-Gain off off AWM Pitch
53 D5 EX god Fx AN Poly 000:THRU 014:Delay LCR 001:Rev Hall 1 002:Chorus 2 off AN Sync Depth off AWM DCF Freq off off AN Pitch
54 D6 Torture Sc FDSP 013:Auto Pan 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM PEG D1Tim off FDSP PW off off FDSP LFO Speed
55 D7 Witches En AWM 004:Chorus 4 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off InsS EQ H-Gain off InsL Vowel off off InsS LFO Freq,InsS D/W Bal
56 D8 Merapi Fx FDSP 004:Chorus 4 050:Stage 1 002:Rev Hall 2 013:Symphonic off AWM PEG Depth,AWM PEG D1Tim off FDSP Pitch off off FDSP Sub Mod.,FDSP Main Mod.
57 D9 Evil Sc AWM 023:EQ 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
58 D10 FM Line Sq AWM 010:Flanger 2 055:Ensemble Detune 002:Rev Hall 2 016:Delay L,R off AWM Volume off InsL D/W Bal off off AWM DCF Freq
59 D11 Fanfare Br AN Poly 024:3Band EQ 016:Echo 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD,AN VCO2 PMD off AN LFO1 Speed off off AN VCF FMD
60 D12 Faraway Se FDSP 000:THRU 000:THRU 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off FDSP Balance
61 D13 DX Atacky Pf AWM 000:THRU 004:Chorus 4 001:Rev Hall 1 006:Celeste 1 off AWM LFO1 AMD off InsL LFO Freq off off AWM Pitch
62 D14 Flivver Fx AN Poly 016:AMP Simulator 011:Flanger 2 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off COM Rev Send off off COM Cho Send
63 D15 Dist 5th Ld AN Layer 024:3Band EQ 038:Distortion 001:Rev Hall 1 015:Ensemble Detune off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN VCF Freq
64 D16 Flow Fx AWM 013:Auto Pan 017:Cross Delay 001:Rev Hall 1 012:Flanger 3 off InsS LFO Freq off AWM FEG Depth off off InsS EQ H-Gain
* Four different types of voice sets are assigned for the Internal 1 (1-32) voices; tables 1-1, 1-2, 1-3 and 1-4 corresponding to the Demonstration Disks 1, 2, 3 and 4, respectively. The same voice sets are assigned for the Internal 1
(33-64) voices. When restoring the factory set data using the Factory Set file (on page 24, Owner‘s Manual), choose the disk containing the appropriate file.
