Yamaha EX5 EN User Manual
Page 48
48
0B
3
00 00 00 - 00 00 7F
FEG 3rd Rate
0C
3
00 00 00 - 00 00 7F
FEG Release1 Rate
0D
3
00 00 00 - 00 00 7F
FEG Release2 Rate
0E
3
00 00 00 - 00 00 03
Loop Segment
0F
3
00 00 00 - 00 00 0E
FEG Rate Scaling Sense
-7 - +7
10
3
00 00 00 - 00 00 0E
I.Touch->Q Level Sense
-7 - +7
11
3
00 00 00 - 00 00 0E
I.Touch->IHR Sense
-7 - +7
12
3
00 00 00 - 00 00 0E
I.Touch->1st Rate Sense
-7 - +7
13
3
00 00 00 - 00 00 0E
I.Touch->Other Rates Sense
-7 - +7
14
3
00 00 00 - 00 00 01
Q enable
15
3
00 00 00 - 00 00 01
LFO enable
16
3
00 00 00 - 00 00 01
FEG enable
17
3
00 00 00 - 00 00 0F
Filter Type
18
3
00 00 00 - 00 01 7F
Fc
19
3
00 00 00 - 00 01 7F
Gain
1A
3
00 00 00 - 00 00 7F
Filter Scaling Break Point 1
1B
3
00 00 00 - 00 00 7F
Filter Scaling Break Point 2
1C
3
00 00 00 - 00 00 7F
Filter Scaling Break Point 3
1D
3
00 00 00 - 00 00 7F
Filter Scaling Break Point 4
1E
3
00 00 00 - 00 01 7F
Filter Scaling Offset 1
1F
3
00 00 00 - 00 01 7F
Filter Scaling Offset 2
20
3
00 00 00 - 00 01 7F
Filter Scaling Offset 3
21
3
00 00 00 - 00 01 7F
Filter Scaling Offset 4
22
3
00 00 00 - 00 00 7F
Fc scaling Sense
23
3
00 00 00 - 00 00 0E
I.Touch->Gain Sense
-7 - +7
24
3
00 00 00 - 00 00 0E
I.Touch->Fc Sense
-7 - +7
25
3
00 00 00 - 00 00 0F
Fc Random Sense
0 - 15
26
3
00 00 00 - 00 00 0E
I.Touch->FEG Level Sense
-7 - +7
27
3
00 00 00 - 00 00 7F
FEG Depth
28
3
00 00 00 - 00 00 01
Q enable
29
3
00 00 00 - 00 00 01
LFO enable
2A
3
00 00 00 - 00 00 01
FEG enable
2B
3
00 00 00 - 00 00 0F
Filter Type
2C
3
00 00 00 - 00 01 7F
Fc
2D
3
00 00 00 - 00 01 7F
Gain
2E
3
00 00 00 - 00 00 7F
Filter Scaling Break Point 1
2F
3
00 00 00 - 00 00 7F
Filter Scaling Break Point 2
30
3
00 00 00 - 00 00 7F
Filter Scaling Break Point 3
31
3
00 00 00 - 00 00 7F
Filter Scaling Break Point 4
32
3
00 00 00 - 00 01 7F
Filter Scaling Offset 1
33
3
00 00 00 - 00 01 7F
Filter Scaling Offset 2
34
3
00 00 00 - 00 01 7F
Filter Scaling Offset 3
35
3
00 00 00 - 00 01 7F
Filter Scaling Offset 4
36
3
00 00 00 - 00 00 7F
Fc scaling Sense
37
3
00 00 00 - 00 00 0E
I.Touch->Gain Sense
-7 - +7
38
3
00 00 00 - 00 00 0E
I.Touch->Fc Sense
-7 - +7
39
3
00 00 00 - 00 00 0F
Fc Random Sense
0 - 15
3A
3
00 00 00 - 00 00 0E
I.Touch->FEG Level Sense
-7 - +7
3B
3
00 00 00 - 00 00 7F
FEG Depth
3C
3
00 00 00 - 00 00 08
Static Filter Type
3D
3
00 00 00 - 00 01 7F
Freq1
3E
3
00 00 00 - 00 00 7F
Boost/Cut1
3F
3
00 00 00 - 00 00 1F
Q or Bandwidth
40
3
00 00 00 - 00 00 0E
I.Touch->B/C1 Sens
41
3
00 00 00 - 00 00 0E
I.Touch->Fr1 Sens.
42
3
00 00 00 - 00 00 07
B/C Random Sens.
43
3
00 00 00 - 00 00 07
Fc Random Sens.
44
3
00 00 00 - 00 01 7F
Freq2
45
3
00 00 00 - 00 00 7F
Boost/Cut2
46
3
00 00 00 - 00 01 7F
reserve
47
3
00 00 00 - 00 00 0E
I.Touch->B/C2 Sens
48
3
00 00 00 - 00 00 0E
I.Touch->Fr2 Sens.
49
3
00 00 00 - 00 00 7F
Fc scaling sens.
4A
3
00 00 00 - 00 00 7F
Gain
4B
3
00 00 00 - 00 00 01
FDSP SW
4C
3
00 00 00 - 00 00 02
Insertion Select SW Bypass,Ins-S On,Ins-L On
ee = Element No.(00 - 7F : Element1 - Element128)
< Table 7 >
Current VL Parameter
Address
Size
Data
Parameter
Description
(H)
(H)
(H)
20
00
00
1
20 - 7F
ELEMENT NAME 1
32-127(ASCII)
00
01
1
20 - 7F
ELEMENT NAME 2
32-127(ASCII)
00
02
1
20 - 7F
ELEMENT NAME 3
32-127(ASCII)
00
03
1
20 - 7F
ELEMENT NAME 4
32-127(ASCII)
00
04
1
20 - 7F
ELEMENT NAME 5
32-127(ASCII)
00
05
1
20 - 7F
ELEMENT NAME 6
32-127(ASCII)
00
06
1
20 - 7F
ELEMENT NAME 7
32-127(ASCII)
00
07
1
20 - 7F
ELEMENT NAME 8
32-127(ASCII)
00
08
1
20 - 7F
ELEMENT NAME 9
32-127(ASCII)
00
09
1
20 - 7F
ELEMENT NAME 10
32-127(ASCII)
00
0A
1
00 - 01
EXPRESSION MODE
BC,VOLUME
00
0B
1
00 - 62
PRESSURE CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
0C
2
01 01 - 00 7F
DEPTH
-127 - +127
00
0E
1
70 - 10
CURVE
-16 - +16
00
0F
1
00 - 62
FILTER CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
10
2
01 01 - 00 7F
DEPTH
-127 - +127
00
12
1
70 - 10
CURVE
-16 - +16
00
13
1
00 - 62
AMPLITUDE CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
14
2
01 01 - 00 7F
DEPTH
-127 - +127
00
16
1
70 - 10
CURVE
-16 - +1
00
17
1
00 - 62
EMBOUCHURE CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
18
2
01 01 - 00 7F
UPPER DEPTH
-127 - +127
00
1A
2
01 01 - 00 7F
LOWER DEPTH
-127 - +127
00
1C
1
00 - 01
MODE
CENTER BASE,
MINIMUM BASE
00
1D
1
00 - 62
TONGUING CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
1E
2
01 01 - 00 7F
DEPTH
-127 - +127
00
20
1
70 - 10
CURVE
-16 - +16
00
21
1
00 - 62
SCREAM CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
22
2
01 01 - 00 7F
DEPTH
-127 - +127
00
24
1
70 - 10
CURVE
-16 - +16
00
25
1
00 - 62
BREATH NOISE CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
26
2
01 01 - 00 7F
DEPTH
-127 - +127
00
28
1
70 - 10
CURVE
-16 - +16
00
29
1
00 - 62
GROWL CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
2A
2
01 01 - 00 7F
DEPTH
-127 - +127
00
2C
1
70 - 10
CURVE
-16 - +16
00
2D
1
00 - 62
THROAT FORMANT CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
2E
2
01 01 - 00 7F
DEPTH
-127 - +127
00
30
1
70 - 10
CURVE
-16 - +16
00
31
1
00 - 62
HARMONIC ENHANCER CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
32
2
01 01 - 00 7F
DEPTH
-127 - +127
00
34
1
70 - 10
CURVE
-16 - +16
00
35
1
00 - 62
DAMPING CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
36
2
01 01 - 00 7F
DEPTH
-127 - +127
00
38
1
70 - 10
CURVE
-16 - +16
00
39
1
00 - 62
ABSORPTION CONTROL NO.
off - 95,AT,
VELOCITY,PB
00
3A
2
01 01 - 00 7F
DEPTH
-127 - +127
00
3C
1
70 - 10
CURVE
-16 - +16
00
3D
1
reserve
00
3E
1
reserve
00
3F
1
40 - 3F
NOTE SHIFT
-64 - +63
00
40
1
reserve
00
41
1
00 - 07
RANDOM PITCH
0 - 7
00
42
1
00 - 7F
NOTE RANGE LOW
C-2 - G8
00
43
1
00 - 7F
NOTE RANGE HIGH
C-2 - G8
00
44
1
reserve
00
45
1
reserve
00
46
1
00 - 60
CROSSFADE SPEED
0 - 96
00
47
1
00 - 32
INTERPOLATE SPEED
0 - 52
00
48
1
00 - 7F
BREATH NOISE LEVEL
0 - 127
00
49
1
00 - 7F
BREAKPOINT 1
C-2 - G8
00
4A
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-6
00
55
1
00 - 7D
BREATH NOISE HPF CUTOFF FREQ
0 - 125
00
56
1
00 - 7F
BREAKPOINT 1
C-2 - G8
00
57
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
00
5A
1
00 - 7F
BREATH NOISE LPF CUTOFF FREQ
0 - 127
00
5B
1
00 - 7F
BREAKPOINT 1
C-2 - G8
00
5C
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
00
5F
1
00 - 16
BREATH NOISE KIND
0 - 22
00
60
1
00 - 01
BREATH NOISE KEY ON RESET
OFF/ON
00
61
1
00 - 20
BREATH NOISE SLIT DRIVE
0 - 32
00
62
1
40 - 3F
BREATH NOISE LEVEL CONTROL BALANCE
-64 - +63
00
63
1
00 - 01
THROAT FORMANT PITCH TRACKING
FIXED/KEY TRACK
00
64
2
00 00 - 01 30
THROAT FORMANT PITCH
0 - 176
00
66
1
00 - 7F
BREAKPOINT 1
C-2 - G8
00
67
2
01 01 - 00 7F
OFFSET 1
-127 - +127
|
|
BREAKPOINT/OFFSET 2-8
00
7E
2
01 01 - 00 7F
THROAT FORMANT INTENSITY
-127 - +127
01
00
1
00 - 7F
BREAKPOINT 1
C-2 - G8
01
01
2
01 01 - 00 7F
OFFSET 1
-127 - +127
|
|
BREAKPOINT/OFFSET 2-4
01
0C
1
40 - 3F
THROAT FORMANT AMOUNT
-64 - +63
01
0D
1
00 - 7F
BREAKPOINT 1
C-2 - G8
01
0E
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-4
01
15
1
00 - 7D
THROAT FORMANT HPF CUTOFF FREQ
0 - 125
01
16
1
00 - 7F
BREAKPOINT 1
C-2 - G8
01
17
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-3
01
1C
1
00 - 7F
THROAT FORMANT LPF CUTOFF FREQ
0 - 127
01
1D
1
00 - 7F
BREAKPOINT 1
C-2 - G8
01
1E
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-3
01
23
1
00 - 7F
DRIVER OUTPUT
0 - 127
01
24
1
00 - 7F
BREAKPOINT 1
C-2 - G8
01
25
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-6
01
30
1
00 - 7F
PIPE/STRING OUTPUT
0 - 127
01
31
1
00 - 7F
BREAKPOINT 1
C-2 - G8
01
32
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-6
01
3D
1
00 - 7F
TAP OUTPUT
0 - 127
01
3E
1
00 - 7F
BREAKPOINT 1
C-2 - G8
01
3F
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-6
01
4A
1
00 - 01
TAP OUTPUT SIGN
-/+
01
4B
1
00 - 02
TAP SETTING
DRIVING POINT,
FIXED,KEY TRACK
01
4C
1
00 - 7F
TAP LOCATION
0 - 127
01
4D
1
00 - 7F
BREAKPOINT 1
C-2 - G8
01
4E
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-8
01
5D
1
00 - 7F
TOTAL AMPLITUDE LEVEL
0 - 127
01
5E
1
00 - 7F
BREAKPOINT 1
C-2 - G8
01
5F
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-8
01
6E
1
00 - 01
PIPE/STRING SHORT LENGTH PITCH TRACKING
FIXED/KEY TRACK
01
6F
2
00 00 - 01 7F
PIPE/STRING SHORT LENGTH
0 - 255
01
71
1
00 - 7F
BREAKPOINT 1
C-2 - G8
