Yamaha EX5 EN User Manual
Page 50
50
06
3A
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-4
06
41
1
00 - 7F
PRESSURE EG DECAY RATE
0 - 127
06
42
1
00 - 7F
BREAKPOINT 1
C-2 - G8
06
43
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-4
06
4A
1
00 - 7F
PRESSURE EG SUSTAIN LEVEL
0 - 127
06
4B
1
00 - 7F
BREAKPOINT 1
C-2 - G8
06
4C
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-4
06
53
1
00 - 7F
PRESSURE EG RELEASE RATE
0 - 127
06
54
1
00 - 7F
BREAKPOINT 1
C-2 - G8
06
55
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2-4
06
5C
1
00 - 02
PRESSURE EG MODE
DISABLE,ADSR,AR
06
5D
1
00 - 10
PITCH & EMBOUCHURE EG VELOCITY SENS TO LEVEL
0 - 16
06
5E
1
70 - 10
PITCH & EMBOUCHURE EG VELOCITY SENS TO RATE
-16 - +16
06
5F
1
00 - 7F
PITCH & EMBOUCHURE EG HOLD TIME
0 - 127
06
60
1
00 - 7F
BREAKPOINT 1
C-2 - G8
06
61
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
06
64
1
40 - 3F
PITCH & EMBOUCHURE EG INITIAL LEVEL
-64 - +63
06
65
1
00 - 7F
BREAKPOINT 1
C-2 - G8
06
66
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
06
69
1
00 - 7F
PITCH & EMBOUCHURE EG ATTACK RATE
0 - 127
06
6A
1
00 - 7F
BREAKPOINT 1
C-2 - G8
06
6B
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
06
6E
1
40 - 3F
PITCH & EMBOUCHURE EG ATTACK LEVEL
-64 - +63
06
6F
1
00 - 7F
BREAKPOINT 1
C-2 - G8
06
70
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
06
73
1
00 - 7F
PITCH & EMBOUCHURE EG DECAY RATE
0 - 127
06
74
1
00 - 7F
BREAKPOINT 1
C-2 - G8
06
75
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
06
78
1
00 - 7F
PITCH & EMBOUCHURE EG RELEASE RATE
0 - 127
06
79
1
00 - 7F
BREAKPOINT 1
C-2 - G8
06
7A
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
06
7D
1
00 - 7F
PITCH & EMBOUCHURE EG RELEASE LEVEL
0 - 127
06
7E
1
00 - 7F
BREAKPOINT 1
C-2 - G8
06
7F
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
02
1
00 - 40
PITCH & EMBOUCHURE EG DEPTH TO EMBOUCHURE
0 - 64
07
03
1
00 - 40
PITCH & EMBOUCHURE EG DEPTH TO PITCH
0 - 64
07
04
1
00 - 7F
VIBRATO DELAY TIME
0 - 127
07
05
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
06
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
09
1
00 - 7F
VIBRATO SUSTAIN LEVEL
0 - 127
07
0A
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
0B
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
0E
1
00 - 7F
VIBRATO DEPTH
0 - 127
07
0F
1
00 - 7F
VIBRATO DEPTH TO EMBOUCHURE
0 - 127
07
10
1
00 - 7F
VIBRATO DEPTH TO PITCH
0 - 127
07
11
1
00 - 7F
VIBRATO DEPTH TO PRESSURE
0 - 127
07
12
2
01 01 - 00 7F
VIBRATO OFFSET
-127 - +127
07
14
1
00 - 7F
VIBRATO SPEED
0 - 127
07
15
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
16
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
19
1
00 - 10
VIBRATO SPEED SHIFT
0 - 16
07
1A
1
00 - 7F
GROWL DEPTH TO PRESSURE
0 - 127
07
1B
2
01 01 - 00 7F
GROWL OFFSET
-127 - +127
07
1D
1
00 - 7F
GROWL SPEED
0 - 127
07
1E
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
1F
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
22
1
00 - 10
AMPLITUDE & FILTER EG VELOCITY SENS TO LEVEL
0 - 16
07
23
1
00 - 10
AMPLITUDE & FILTER EG VELOCITY SENS TO RATE
0 - 16
07
24
1
00 - 7F
AMPLITUDE & FILTER EG ATTACK RATE 1
0 - 127
07
25
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
26
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
29
1
00 - 7F
AMPLITUDE & FILTER EG ATTACK LEVEL 1
0 - 127
07
2A
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
2B
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
2E
1
00 - 7F
AMPLITUDE & FILTER EG ATTACK RATE 2
0 - 127
07
2F
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
30
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
33
1
00 - 7F
AMPLITUDE & FILTER EG DECAY RATE
0 - 127
07
34
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
35
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
38
1
00 - 7F
AMPLITUDE & FILTER EG SUSTAIN LEVEL
0 - 127
07
39
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
3A
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
3D
1
00 - 7F
AMPLITUDE & FILTER EG RELEASE RATE
0 - 127
07
3E
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
3F
1
40 - 3F
OFFSET 1
-64 - +63
|
|
BREAKPOINT/OFFSET 2
07
42
1
00 - 7F
AMPLITUDE & FILTER EG DEPTH TO AMPLITUDE
0 - 127
07
43
2
01 01 - 00 7F
AMPLITUDE & FILTER EG DEPTH TO FILTER
-127 - +127
07
45
2
02 00 - 01 7F
PITCH COMPENSATION
-256 - +255
07
47
1
00 - 7F
BREAKPOINT 1
C-2 - G8
07
48
2
02 00 - 01 7F
OFFSET 1
-256 - +255
|
|
BREAKPOINT/OFFSET 2-12
07
6B
2
00 00 - 7F 7F
PIPE/STRING LENGTH C-2
0 - 16383
|
|
PIPE/STRING LENGTH C#-2 - F#8
09
69
2
00 00 - 7F 7F
PIPE/STRING LENGTH G8
0 - 16383
09
6B
1
00 - 7F
PIPE/STRING LENGTH DERIVATIVE C-2
0 - 127
|
|
PIPE/STRING LENGTH DERIVATIVE C#-2 - F#8
0A
6A
1
00 - 7F
PIPE/STRING LENGTH DERIVATIVE G8
0 - 127
< Table 8 >
Current Performance / Common Bulk
Address
Size
Data
Parameter
Description
(H)
(H)
(H)
10
00
00
12
Performance Name
ASCII
1
00 - 7F
Category
1
00 - 7F
Total Volume
1
00 - 01
TG/Master KBD
1
00 - 7F
Reverb Type
1
00 - 7F
Reverb Parameter1
1
00 - 7F
Reverb Parameter2
1
00 - 7F
Reverb Parameter3
1
00 - 7F
Reverb Parameter4
1
00 - 7F
Reverb Parameter5
1
00 - 7F
Reverb Parameter6
1
00 - 7F
Reverb Parameter7
1
00 - 7F
Reverb Parameter8
1
00 - 7F
Reverb Parameter9
1
00 - 7F
Reverb Parameter10
1
00 - 7F
Reverb Parameter11
1
00 - 7F
Reverb Parameter12
2
00 00 - FF FF
Reverb Parameter13
2
00 00 - FF FF
Reverb Parameter14
1
00 - 7F
Reverb Return
1
00 - 7F
Reverb PAN
1
reserve
1
00 - 7F
Chorus Type
2
00 00 - FF FF
Chorus Parameter1
2
00 00 - FF FF
Chorus Parameter2
2
00 00 - FF FF
Chorus Parameter3
2
00 00 - FF FF
Chorus Parameter4
1
00 - 7F
Chorus Parameter5
1
00 - 7F
Chorus Parameter6
1
00 - 7F
Chorus Parameter7
1
00 - 7F
Chorus Parameter8
1
00 - 7F
Chorus Parameter9
1
00 - 7F
Chorus Parameter10
1
00 - 7F
Chorus Parameter11
1
00 - 7F
Chorus Parameter12
1
00 - 7F
Chorus Return
1
00 - 7F
Chorus PAN
1
00 - 7F
Send Chorus to Reverb
1
00 - 06
Arpeggiater Tempo Control
3
reserve
1
00 - FF
Bend Wheel Depth/Curve
1
00 - 7F
Bend Wheel Offset
1
00 - FF
Modulation Wheel1 Depth/Curve
1
00 - 7F
Modulation Wheel1 Offset
1
00 - FF
CH After Depth/Curve
1
00 - 7F
CH After Offset
1
00 - 7F
Modulation Wheel2 CC Number
1
00 - FF
Modulation Wheel2 Depth/Curve
1
00 - 7F
Modulation Wheel2 Offset
1
00 - 7F
Foot Controller CC Number
1
00 - FF
Foot Controller Depth/Curve
1
00 - 7F
Foot Controller Offset
1
00 - 7F
Breath Controller CC Number
1
00 - FF
Breath Controller Depth/Curve
1
00 - 7F
Breath Controller Offset
1
00 - 7F
Ribbon Controller CC Number
1
00 - FF
Ribbon Controller Depth/Curve
1
00 - FF
Ribbon Hold/Ribbon Controller Offset
1
00 - 7F
Knob1 CC Number
1
00 - FF
Knob1 Depth/Curve
1
00 - 7F
Knob1 Offset
1
00 - 7F
Knob2 CC Number
1
00 - FF
Knob2 Depth/Curve
1
00 - 7F
Knob2 Offset
1
00 - 7F
Knob3 CC Number
1
00 - FF
Knob3 Depth/Curve
1
00 - 7F
Knob3 Offset
1
00 - 7F
Knob4 CC Number
1
00 - FF
Knob4 Depth/Curve
1
00 - 7F
Knob4 Offset
1
00 - 7F
Knob5 CC Number
1
00 - FF
Knob5 Depth/Curve
1
00 - 7F
Knob5 Offset
1
00 - 7F
Knob6 CC Number
1
00 - FF
Knob6 Depth/Curve
1
00 - 7F
Knob6 Offset
1
00 - FF
Arpeggiater On/Type
1
00 - 7F
Arpeggiater Hold/Tx A On/Tx B On/MIDI Channel
1
00 - 7F
Note Limit Low
1
00 - 7F
Note Limit High
1
00 - FF
Arpeggiater Tempo
1
00 - 7F
Knob1Scene1
1
00 - 7F
Knob1 Scene2
1
00 - 7F
Knob2 Scene1
1
00 - 7F
Knob2 Scene2
1
00 - 7F
Knob3 Scene1
1
00 - 7F
Knob3 Scene2
1
00 - 7F
Knob4 Scene1
1
00 - 7F
Knob4 Scene2
1
00 - 7F
Knob5 Scene1
1
00 - 7F
Knob5 Scene2
1
00 - 7F
Knob6 Scene1
1
00 - 7F
Knob6 Scene2
