Yamaha EX5 EN - Manual (Page 10)

10
Internal 1-1 (1-64)
MSB=63
LSB=2
Effect Controller
No. Bnk Voice Name Cat Type Ins-S Type Ins-L Type Reverb Type Chorus Type PB MW AT MW2 FC BC Rbn
1 A1 Made in USA Pf AWM 001:Chorus 1 055:Ensemble Detune 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
2 A2 Jazz Grand Pf AWM 000:THRU 058:3Band EQ 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
3 A3 Georgia Pf AWM 023:EQ 055:Ensemble Detune 001:Rev Hall 1 004:Chorus 4 off COM Cho Send,InsL D/W Bal off AWM DCF Freq off off AWM Pitch
4 A4 Lead Switch Gt AWM 016:AMP Simulator 058:3Band EQ 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
5 A5 Pulse Smack Ba FDSP 000:THRU 000:THRU 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
6 A6 Snoop Bass Ba AN Poly 024:3Band EQ 071:Attack Lofi 001:Rev Hall 1 016:Delay L,R off AN VCO2 Edge off AN Feedback off off
COM Port SW,
AN Port Time
7 A7 Hardstep Ba AN Poly 000:THRU 022:Ambience 001:Rev Hall 1 016:Delay L,R off AN Sync Pitch off AN VCO2 Edge off off AN Feedback
8 A8 Hardsequence Ba FDSP 016:AMP Simulator 015:Delay LR 001:Rev Hall 1 014:Phaser off FDSP Drive off InsS Drive off off FDSP Egde Bias
9 A9 Swell String St AWM 000:THRU 058:3Band EQ 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD,AWM LFO2Depth off AWM DCF Freq off off AWM Pitch
10 A10 BreathChoir En AWM 024:3Band EQ 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD,AWM LFO2Depth off AWM Volume off off InsL Vowel
11 A11 Trumpet Br VL 000:THRU 000:THRU 001:Rev Hall 1 001:Chorus 1 VL Embouchure VL PMD
VL Pressure,
VL Amplitude
VL Flt Freq off off VL Embouchure
12 A12 Matrix Br AWM 024:3Band EQ 004:Chorus 4 002:Rev Hall 2 016:Delay L,R off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
13 A13 Mean Lead Ld AN FDSP 024:3Band EQ 062:V-Distortion 001:Rev Hall 1 016:Delay L,R off
AWM LFO1 PMD,AN VCO1 PMD,
AN VCO2 PMD
AWM LFO2Depth InsL D/W Bal off off AN Pitch,AWM Pitch
14 A14 Earth Lead Ld AN Layer 000:THRU 000:THRU 002:Rev Hall 2 016:Delay L,R off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN VCF Freq
15 A15 Pro Lead Ld AN Poly 000:THRU 015:Delay LR 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD,AN VCO2 PMD off AN LFO1 Speed off off AN VCF Freq
16 A16 Minor Vocals Ld AWM 017:Exciter 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off off off AWM DCF Freq off off AWM DCF Freq
17 B1 Bottled Out Pd AWM 000:THRU 018:Rotary Speaker 1 006:Rev Stage 1 001:Chorus 1 off AWM LFO2Depth off AWM Volume off off
InsL LFO Freq,
InsL LFO Depth
18 B2 ComeOnHigh Pd FDSP 024:3Band EQ 058:3Band EQ 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 FMD,AWM LFO1 AMD off FDSP Pitch off off FDSP LFO Speed
19 B3 AN Layer Pd AN Poly 000:THRU 011:Flanger 2 001:Rev Hall 1 013:Symphonic off AN VCO1 PMD off AN VCF Freq off off AN Pitch
20 B4 Adventure Fx FDSP 000:THRU 015:Delay LR 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
21 B5 Shakuhachi Et VL 024:3Band EQ 022:Ambience 001:Rev Hall 1 001:Chorus 1 VL Embouchure VL PMD off VL Growl,VL Pressure off off VL Pitch
22 B6 Seven Se FDSP 001:Chorus 1 000:THRU 001:Rev Hall 1 015:Ensemble Detune off AWM DCF Freq off AWM Volume off off AWM Pitch
23 B7 Pulse EP Sc FDSP 024:3Band EQ 017:Cross Delay 001:Rev Hall 1 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM Pitch
24 B8 Loved Up Sc FDSP 004:Chorus 4 055:Ensemble Detune 006:Rev Stage 1 016:Delay L,R off AWM LFO1 PMD off FDSP Balance off off InsL EQ H-Gain
25 B9 Stonk Sc AWM 018:Compressor 058:3Band EQ 007:Rev Stage 2 003:Chorus 3 off AWM LFO1 FMD off AWM Volume off off
AWM Pitch,
AWM Pitch
26 B10 Ring EP Sc FDSP 009:Flanger 1 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off FDSP Sub Mod. off off AWM Pitch
27 B11 Futopia Pd FDSP 000:THRU 055:Ensemble Detune 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
28 B12 Gronk Sc FDSP 000:THRU 001:Chorus 1 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off InsL D/W Bal off off AWM Pitch
29 B13 Straight Sc AWM 008:Celeste 4 017:Cross Delay 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
30 B14 Sync Echo Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 014:Phaser off AWM FEG D1Tim off InsL D/W Bal off off AWM DCF Freq
31 B15 Down Spiral Se AWM 000:THRU 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off off off off COM Cho Send
32 B16 FM Line Sq AWM 010:Flanger 2 055:Ensemble Detune 002:Rev Hall 2 016:Delay L,R off AWM Volume off InsL D/W Bal off off AWM DCF Freq
33 C1 4 by 4 Dr AWM 016:AMP Simulator 062:V-Distortion 001:Rev Hall 1 001:Chorus 1 off AWM LFO2Speed off COM Rev Send off off AWM DCF Freq
34 C2 4 Osc Sweep Fx AWM 000:THRU 017:Cross Delay 002:Rev Hall 2 004:Chorus 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
35 C3 Countryman Sc FDSP 024:3Band EQ 063:V-Flanger 008:Rev Plate 016:Delay L,R off AWM LFO1 FMD off FDSP Pickup Pos. off off AWM DCF Freq
36 C4 Air Stabs Sc AN Poly 010:Flanger 2 017:Cross Delay 001:Rev Hall 1 006:Celeste 1 off AN VCF FMD off AN LFO1 Speed off off
AN FEG Depth,
AN Sync Depth
37 C5 AnalogSQ Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
38 C6 Art of Love Vo FDSP 017:Exciter 015:Delay LR 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
39 C7 Kick & Snare Dr AN Layer 024:3Band EQ 027:Gate Reverb 001:Rev Hall 1 016:Delay L,R off AN VCF FMD off AN VCF Freq off off AN Pitch
40 C8 Beades Se FDSP 000:THRU 021:Auto Pan 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off FDSP Pitch off off FDSP LFO Depth
41 C9 BigArpeggio Sq AWM 013:Auto Pan 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM FEG Depth off InsL D/W Bal off off AWM DCF Freq
42 C10 Big Orch Co AWM 024:3Band EQ 054:Pitch Change 2 002:Rev Hall 2 015:Ensemble Detune off AWM LFO1 PMD off AWM Volume off off AWM DCF Freq
43 C11 Bip Sc AWM 022:Phaser 017:Cross Delay 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off COM Cho Send off off AWM DCF Freq
44 C12 Blockhead Sc AWM 010:Flanger 2 040:AMP Simulator 001:Rev Hall 1 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off InsS LFO Freq
45 C13 Blue Sc AWM 009:Flanger 1 017:Cross Delay 006:Rev Stage 1 001:Chorus 1 off AWM LFO1 FMD off AWM Volume off off AWM LFO1 AMD
46 C14 Brush 'Em Gt AWM 001:Chorus 1 000:THRU 002:Rev Hall 2 001:Chorus 1 off AWM LFO1 PMD off AWM AEG D2Tim off off AWM LFO1 PMD
47 C15 Clickbell Cp AWM 017:Exciter 058:3Band EQ 001:Rev Hall 1 001:Chorus 1 off AWM LFO1 PMD off AWM LFO1Speed off off InsS HPF Cutoff
48 C16 Cloud Nine Pd AWM 000:THRU 011:Flanger 2 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off AWM DCF Freq
49 D1 Adventure Fx FDSP 000:THRU 015:Delay LR 002:Rev Hall 2 009:Celeste 4 off AWM LFO1 PMD off AWM DCF Freq off off AWM DCF Freq
50 D2 Descender Fx AN Poly 000:THRU 011:Flanger 2 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off AN LFO1 Speed off off
AN VCF Freq,
AN VCF Reso
51 D3 Blue Lead Gt FDSP 016:AMP Simulator 000:THRU 001:Rev Hall 1 017:Ctrl. Delay off AWM LFO1 PMD off InsS D/W Bal off off AWM LFO1 PMD
52 D4 DigiWorld Sq AWM 024:3Band EQ 053:Pitch Change 1 001:Rev Hall 1 016:Delay L,R off AWM LFO2Depth,AWM LFO2Speed off InsS EQ M-Gain off off AWM Pitch
53 D5 EX god Fx AN Poly 000:THRU 014:Delay LCR 001:Rev Hall 1 002:Chorus 2 off AN Sync Depth off AWM DCF Freq off off AN Pitch
54 D6 Torture Sc FDSP 013:Auto Pan 000:THRU 001:Rev Hall 1 001:Chorus 1 off AWM PEG D1Tim off FDSP PW off off FDSP LFO Speed
55 D7 Witches En AWM 004:Chorus 4 064:Talking Modulator 001:Rev Hall 1 015:Ensemble Detune off InsS EQ H-Gain off InsL Vowel off off
InsS LFO Freq,
InsS D/W Bal
56 D8 Merapi Fx FDSP 004:Chorus 4 050:Stage 1 002:Rev Hall 2 013:Symphonic off AWM PEG Depth,AWM PEG D1Tim off FDSP Pitch off off
FDSP Sub Mod.,
FDSP Main Mod.
57 D9 Evil Sc AWM 023:EQ 015:Delay LR 001:Rev Hall 1 015:Ensemble Detune off AWM LFO1 PMD off InsL D/W Bal off off AWM DCF Freq
58 D10 FM Line Sq AWM 010:Flanger 2 055:Ensemble Detune 002:Rev Hall 2 016:Delay L,R off AWM Volume off InsL D/W Bal off off AWM DCF Freq
59 D11 Fanfare Br AN Poly 024:3Band EQ 016:Echo 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD,AN VCO2 PMD off AN LFO1 Speed off off AN VCF FMD
60 D12 Faraway Se FDSP 000:THRU 000:THRU 009:Rev White Room 016:Delay L,R off AWM LFO1 PMD off AWM LFO1Speed off off FDSP Balance
61 D13 DX Atacky Pf AWM 000:THRU 004:Chorus 4 001:Rev Hall 1 006:Celeste 1 off AWM LFO1 AMD off InsL LFO Freq off off AWM Pitch
62 D14 Flivver Fx AN Poly 016:AMP Simulator 011:Flanger 2 001:Rev Hall 1 001:Chorus 1 off AN VCO1 PMD off COM Rev Send off off COM Cho Send
63 D15 Dist 5th Ld AN Layer 024:3Band EQ 038:Distortion 001:Rev Hall 1 015:Ensemble Detune off AN VCO1 PMD,AN VCO2 PMD off AN VCF Freq off off AN VCF Freq
64 D16 Flow Fx AWM 013:Auto Pan 017:Cross Delay 001:Rev Hall 1 012:Flanger 3 off InsS LFO Freq off AWM FEG Depth off off InsS EQ H-Gain
* Four different types of voice sets are assigned for the Internal 1 (1-32) voices; tables 1-1, 1-2, 1-3 and 1-4 corresponding to the Demonstration Disks 1, 2, 3 and 4, respectively. The same voice sets are assigned for the Internal 1
(33-64) voices. When restoring the factory set data using the Factory Set file (on page 24, Owner‘s Manual), choose the disk containing the appropriate file.
