Page 37
37
[20] AUTO WAH
Controller
01. LFO frequency
0.0Hz~39.70Hz
❍
02. LFO depth
0~127
❍
03. cutoff frequency offset
0~127
❍
04. resonanse
1~12.0
❍
05 ~ 08. are the same as parameter
✽
.
❍
09. dry / wet balance
D63>W ~ D=W ~ D ❍ [21] TOUCH WAH Controller 01. sensitive 0~127 ❍ 02. cutoff frequency offset 0~127 ❍ 03. resonanse 1~12.0 ❍ 04 ~ 07.are the same as parameter ✽ . ❍ 08. dry / wet balance D63>W ~ D=W ~ D ❍ [22] PHASER Controller 01. LFO frequency 0.0Hz~39.70Hz ❍ 02. LFO depth 0~127 ❍ 03. phase shift offset 0~127 04. feedback gain –63~+63 ❍ 05. stage 4,5,6 ❍ 06. diffusion mono/stereo 07 ~ 10. are the same as parameter ✽ . ❍ 11. dry / wet balance D63>W ~ D=W ~ D ❍ [23] EQ Controller 01 ~ 04. are the same as parameter ✽ . ❍ [24] 3BAND EQ Controller 01. EQ low frequency 50Hz~2.0kHz ❍ 02. EQ low gain –12dB~+12dB ❍ 03. EQ mid frequency 100Hz~10.0kHz ❍ 04. EQ mid gain –12dB~+12dB ❍ 05. EQ mid Q 1~12.0 ❍ 06. EQ high frequency 500Hz~16.0kHz ❍ 07. EQ high gain –12dB~+12dB ❍ 08. input mode mono/stereo 4. Insertion Effect 2 [0] thru [1]~[5]CHORUS1~5 Controller 01. LFO frequency 0.0Hz~39.70Hz ❍ 02. LFO depth 0~127 ❍ 03. feedback gain –63~+63 ❍ 04. delay offset 0.0ms~50.0ms 05 ~ 08. are the same as parameter ✽ . ❍ 09. EQ mid frequency 100Hz~10.0kHz ❍ 10. EQ mid gain –12dB~+12dB ❍ 11. EQ mid Q 1~12.0 ❍ 12. input mode mono/stereo 13. dry / wet balance D63>W ~ D=W ~ D ❍ [10]~[12] FLANGER1~3 Controller 01. LFO frequency 0.0Hz~39.70Hz ❍ 02. LFO depth 0~127 ❍ 03. feedback gain –63~+63 ❍ 04. delay offset 0.0ms~50.0ms 05 ~ 08. are the same as parameter ✽ . ❍ 09. EQ mid frequency 100Hz~10.0kHz ❍ 10. EQ mid gain –12dB~+12dB ❍ 11. EQ mid Q 1~12.0 ❍ 12. LFO phase difference –180deg~+180deg 13. dry / wet balance D63>W ~ D=W ~ D ❍ [13] SYMPHONIC Controller 01. LFO frequency 0.0Hz~39.70Hz ❍ 02. LFO depth 0~127 ❍ 03. delay offset 0.0ms~50.0ms 04 ~ 07. are the same as parameter ✽ . ❍ 08. EQ mid frequency 100Hz~10.0kHz ❍ 09. EQ mid gain –12dB~+12dB ❍ 10. EQ mid Q 1~12.0 ❍ 11. dry / wet balance D63>W ~ D=W ~ D ❍ [14] DELAY L,C,R Controller 01. delay time L 0.1ms~1486.0ms 02. delay time R 0.1ms~1486.0ms 03. delay time C 0.1ms~1486.0ms 04. feedback time 0.1ms~1486.0ms 05. feedback gain –63~+63 ❍ 06. delay level C 0~127 ❍ 07. feedback high damp 0.1~1.0 08 ~ 11. are the same as parameter ✽ . ❍ 12. dry / wet balance D63>W ~ D=W ~ D ❍ [15] DELAY L,R Controller 01. delay time L 0.1ms~1486.0ms 02. delay time R 0.1ms~1486.0ms 03. feedback time 1 0.1ms~1486.0ms 04. feedback time 2 0.1ms~1486.0ms 05. feedback gain –63~+63 ❍ 06. feedback high damp 0.1~1.0 07 ~ 10. are the same as parameter ✽ . ❍ 11. dry / wet balance D63>W ~ D=W ~ D ❍ [16] ECHO Controller 01. delay time L1 0.1ms~743.0ms 02. feedback gain L –63~+63 ❍ 03. delay time R1 0.1ms~743.0ms 04. feedback gain R –63~+63 ❍ 05. feedback high damp 0.1~1.0 06. delay time L2 0.1ms~743.0ms 07. delay time R2 0.1ms~743.0ms 08. delay level 2 0~127 ❍ 09 ~ 12. are the same as parameter ✽ . ❍ 13. dry / wet balance D63>W ~ D=W ~ D ❍ [17] CROSS DELAY Controller 01. delay time L>R 0.1ms~743.0ms 02. delay time R>L 0.1ms~743.0ms 03. feedback gain –63~+63 ❍ 04. input select ( type ) L, R, L&R 05. feedback high damp 0.1~1.0 06 ~ 09. are the same as parameter ✽ . ❍ 10. dry / wet balance D63>W ~ D=W ~ D ❍ [18] ROTARY SPEAKER1 Controller 01. LFO frequency 0.0Hz~39.70Hz ❍ 02. LFO depth 0~127 ❍ 03 ~ 06. are the same as parameter ✽ . ❍ 07. EQ mid frequency 100Hz~10.0kHz ❍ 08. EQ mid gain –12dB~+12dB ❍ 09. EQ mid Q 1~12.0 ❍ 10. dry / wet balance D63>W ~ D=W ~ D ❍ [19] ROTARY SPEAKER2 Controller 01. rotor speed 0.0Hz~39.70Hz ❍ 02. drive low 0~127 ❍ 03. drive high 0~127 ❍ 04. low / high balance L63>H ~ L=H ~ L ❍ 05. mic L-R angle 0deg~180deg 06. divide frequency 100Hz~10.0kHz 07 ~ 10. are the same as parameter ✽ . ❍ [20]TREMOLO Controller 01. LFO frequency 0.0Hz~39.70Hz ❍ 02. AM depth 0~127 ❍ 03. PM depth 0~127 ❍ 04. LFO phase difference –180deg~+180deg 05 ~ 08. are the same as parameter ✽ . ❍ 09. EQ mid frequency 100Hz~10.0kHz ❍ 10. EQ mid gain –12dB~+12dB ❍ 11. EQ mid Q 1~12.0 ❍ 12. input mode mono/stereo [21]AUTO PAN Controller 01. LFO frequency 0.0Hz~39.70Hz ❍ 02. L/R depth 0~127 ❍ 03. F/R depth 0~127 ❍ 04. PAN direction L<>R, L>>R, L< 05 ~ 08. are the same as parameter ✽ . ❍ 09. EQ mid frequency 100Hz~10.0kHz ❍ 10. EQ mid gain –12dB~+12dB ❍ 11. EQ mid Q 1~12.0 ❍ [22] Ambience Controller 01. delay time 0.0ms~50.0ms 02. wet output phase normal/inverse ❍ 03 ~ 06. are the same as parameter ✽ . ❍ 07. dry / wet balance D63>W ~ D=W ~ D ❍ [23] PHASER1 Controller 01. LFO frequency 0.0Hz~39.70Hz ❍ 02. LFO depth 0~127 ❍ 03. phase shift offset 0~127 04. feedback gain –63~+63 ❍ 05. stage 4, 5, 6, 7, 8, 9, 10, 11, 12 ❍ 06. diffusion mono/stereo 07 ~ 10. are the same as parameter ✽ . ❍ 11. dry / wet balance D63>W ~ D=W ~ D ❍
[6]~[9] CELESTE1~4
