Yamaha EX5 EN - Manual (Page 47)

47
08 2 00 00 - 01 7F Foot Controller Assign Switch H
09 2 00 00 - 01 7F Foot Controller Assign Switch L
0A 2 00 00 - 01 7F Breath Controller Assign Switch H
0B 2 00 00 - 01 7F Breath Controller Assign Switch L
0C 2 00 00 - 01 7F Ribbon Controller Assign Switch H
0D 2 00 00 - 01 7F Ribbon Controller Assign Switch L
0E 2 00 00 - 01 7F Knob1 Assign Switch H
0F 2 00 00 - 01 7F Knob1 Assign Switch L
10 2 00 00 - 01 7F Knob2 Assign Switch H
11 2 00 00 - 01 7F Knob2 Assign Switch L
12 2 00 00 - 01 7F Knob3 Assign Switch H
13 2 00 00 - 01 7F Knob3 Assign Switch L
14 2 00 00 - 01 7F Knob4 Assign Switch H
15 2 00 00 - 01 7F Knob4 Assign Switch L
16 2 00 00 - 01 7F Knob5 Assign Switch H
17 2 00 00 - 01 7F Knob5 Assign Switch L
18 2 00 00 - 01 7F Knob6 Assign Switch H
19 2 00 00 - 01 7F Knob6 Assign Switch L
1A 2 00 00 - 00 7F VC1 Control Depth
1B 2 00 00 - 00 7F VC2 Control Depth
1C 2 00 00 - 00 7F VC3 Control Depth
1D 2 00 00 - 00 7F VC4 Control Depth
1E 2 00 00 - 00 7F VC5 Control Depth
1F 2 00 00 - 00 7F VC6 Control Depth
20 2 00 00 - 00 7F VC7 Control Depth
21 2 00 00 - 00 7F VC8 Control Depth
22 2 00 00 - 00 7F VC9 Control Depth
23 2 00 00 - 00 7F VC10 Control Depth
24 2 00 00 - 00 7F VC11 Control Depth
25 2 00 00 - 00 7F VC12 Control Depth
26 2 00 00 - 00 7F VC13 Control Depth
27 2 00 00 - 00 7F VC14 Control Depth
28 2 00 00 - 00 7F VC15 Control Depth
29 2 00 00 - 00 7F VC16 Control Depth
2A 2 00 00 - 01 7F VC1 Destination Assign Number
2B 2 00 00 - 01 7F VC2 Destination Assign Number
2C 2 00 00 - 01 7F VC3 Destination Assign Number
2D 2 00 00 - 01 7F VC4 Destination Assign Number
2E 2 00 00 - 01 7F VC5 Destination Assign Number
2F 2 00 00 - 01 7F VC6 Destination Assign Number
30 2 00 00 - 01 7F VC7 Destination Assign Number
31 2 00 00 - 01 7F VC8 Destination Assign Number
32 2 00 00 - 01 7F VC9 Destination Assign Number
33 2 00 00 - 01 7F VC10 Destination Assign Number
34 2 00 00 - 01 7F VC11 Destination Assign Number
35 2 00 00 - 01 7F VC12 Destination Assign Number
36 2 00 00 - 01 7F VC13 Destination Assign Number
37 2 00 00 - 01 7F VC14 Destination Assign Number
38 2 00 00 - 01 7F VC15 Destination Assign Number
39 2 00 00 - 01 7F VC16 Destination Assign Number
3A 2 00 00 - 00 0F VC1 Destination Assign Element SW
3B 2 00 00 - 00 0F VC2 Destination Assign Element SW
3C 2 00 00 - 00 0F VC3 Destination Assign Element SW
3D 2 00 00 - 00 0F VC4 Destination Assign Element SW
3E 2 00 00 - 00 0F VC5 Destination Assign Element SW
3F 2 00 00 - 00 0F VC6 Destination Assign Element SW
40 2 00 00 - 00 0F VC7 Destination Assign Element SW
41 2 00 00 - 00 0F VC8 Destination Assign Element SW
42 2 00 00 - 00 0F VC9 Destination Assign Element SW
43 2 00 00 - 00 0F VC10 Destination Assign Element SW
44 2 00 00 - 00 0F VC11 Destination Assign Element SW
45 2 00 00 - 00 0F VC12 Destination Assign Element SW
46 2 00 00 - 00 0F VC13 Destination Assign Element SW
47 2 00 00 - 00 0F VC14 Destination Assign Element SW
48 2 00 00 - 00 0F VC15 Destination Assign Element SW
49 2 00 00 - 00 0F VC16 Destination Assign Element SW
4A 2 00 10 - 00 58 Pitch Bend Upper Depth
4B 2 00 10 - 00 58 Pitch Bend Lower Depth
4C 2 00 00 - 00 7F Knob1 Scene1
4D 2 00 00 - 00 7F Knob1 Scene2
4E 2 00 00 - 00 7F Knob1 Initial
4F 2 00 00 - 00 7F Knob2 Scene1
50 2 00 00 - 00 7F Knob2 Scene2
51 2 00 00 - 00 7F Knob2 Initial
52 2 00 00 - 00 7F Knob3 Scene1
53 2 00 00 - 00 7F Knob3 Scene2
54 2 00 00 - 00 7F Knob3 Initial
55 2 00 00 - 00 7F Knob4 Scene1
56 2 00 00 - 00 7F Knob4 Scene2
57 2 00 00 - 00 7F Knob4 Initial
58 2 00 00 - 00 7F Knob5 Scene1
59 2 00 00 - 00 7F Knob5 Scene2
5A 2 00 00 - 00 7F Knob5 Initial
5B 2 00 00 - 00 7F Knob6 Scene1
5C 2 00 00 - 00 7F Knob6 Scene2
5D 2 00 00 - 00 7F Knob6 Initial
5E 2 00 00 - 00 01 Arpeggiater On
5F 2 00 00 - 00 7F Arpeggiater Type
60 2 00 00 - 00 7F Arpeggiater Note Limit Low
61 2 00 00 - 00 7F Arpeggiater Note Limit High
62 2 00 00 - 01 7F Arpeggiater Tempo
< Table 5 >
Current Voice / Element Parameter 1
Address Size Data Parameter Description
(H) (H) (H)
60 ee 00 3 00 00 00 - 00 00 03 Wave Ban
01 3 00 00 00 - 00 00 03 Element Type AWM,VL,AN,DRUM
02 3 00 00 00 - 00 00 7F Element Volume
03 3 00 00 00 - 00 1F 7F Wave Number
04 3 00 00 00 - 00 00 01 Random PAN
05 3 00 00 00 - 00 00 7F PAN(Random Depth)
06 3 00 00 00 - 00 00 01 Release Loop
07 3 00 00 00 - 00 00 01 One Shot Flag
08 3 00 00 00 - 00 00 01 REVS
09 3 00 00 00 - 00 00 01 Vce Flag
0A 3 00 00 00 - 00 00 0F Scaling PAN Depth
0B 3 00 00 00 - 00 00 7F Tune Fine
0C 3 00 00 00 - 00 00 7F Tune Coarse
0D 3 00 00 35 - 00 01 4B Detune
0E 3 00 00 00 - 00 00 7F Note Limit (Low)
0F 3 00 00 00 - 00 00 7F Note Limit(High)
10 3 00 00 00 - 00 00 7F Note Cross Fade
11 3 00 00 00 - 00 00 7F Velocity Limit(Low)
12 3 00 00 00 - 00 00 7F Velocity Limit(High)
13 3 00 00 00 - 00 00 7F Velocity Cross Fade
14 3 00 00 00 - 00 00 7F ExpressionLimit Low
15 3 00 00 00 - 00 00 7F Key On Delay
16 3 00 00 00 - 00 00 03 LFO Wave
17 3 reserve
18 3 00 00 00 - 00 00 3F LFO Freqency
19 3 00 00 00 - 00 01 7F PMD
1A 3 00 00 00 - 00 00 01 PINV
1B 3 00 00 00 - 00 00 7F AMD
1C 3 00 00 00 - 00 00 01 CINV
1D 3 00 00 00 - 00 00 7F CMD
1E 3 00 00 00 - 00 00 01 Sync
1F 3 00 00 00 - 00 00 7F Delay Vib. Start Time
20 3 00 00 00 - 00 01 7F LFO Fade Time
21 3 00 00 00 - 00 00 0F Freq Random Sense 0 - 15
22 3 00 00 00 - 00 00 0E Freq Vel Sense -7 - +7
23 3 00 00 00 - 00 00 3F LFO Freqency
24 3 00 00 00 - 00 00 03 LFO Wave Phase
25 3 00 00 00 - 00 00 07 LFO Wave Type
26 3 00 00 00 - 00 00 7F LFO Destination No.
27 3 00 00 00 - 00 00 7F LFO Depth
28 3 00 00 00 - 00 00 01 Sync
29 3 00 00 00 - 00 00 7F Delay Vib. Start Time
2A 3 00 00 00 - 00 01 7F LFO Fade Time
2B 3 00 00 00 - 00 00 1F Micro Tuning Table No.
2C 3 00 00 00 - 00 00 07 Pitch Scaling
2D 3 00 00 00 - 00 00 7F Pitch Scaling Center Note
2E 3 00 00 00 - 00 01 7F Initial Level(cent)
2F 3 00 00 00 - 00 01 7F 1st Level(cent)
30 3 00 00 00 - 00 01 7F 2nd Level(cent)
31 3 00 00 00 - 00 01 7F 3rd Level(cent)
32 3 00 00 00 - 00 01 7F Release1 Level(cent)
33 3 00 00 00 - 00 01 7F Release2 Level(cent)
34 3 00 00 28 - 00 00 58 Pitch EG Depth
35 3 00 00 00 - 00 00 7F Hold Time
36 3 00 00 00 - 00 00 7F 1st Rate
37 3 00 00 00 - 00 00 7F 2nd Rate
38 3 00 00 00 - 00 00 7F 3rd Rate
39 3 00 00 00 - 00 00 7F Release1 Rate
3A 3 00 00 00 - 00 00 7F Release2 Rate
3B 3 00 00 00 - 00 00 03 Loop Segment
3C 3 00 00 00 - 00 00 0E PEG Rate Scaling Sense -7 - +7
3D 3 00 00 00 - 00 00 0F Pitch Random Sense 0 - 15
3E 3 00 00 00 - 00 00 0E I.Touch->IHR Sense -7 - +7
3F 3 00 00 00 - 00 00 0E I.Touch->1st Rate Sense -7 - +7
40 3 00 00 00 - 00 00 0E I.Touch->Other Rates Sense -7 - +7
41 3 00 00 00 - 00 00 0E ITouch->PEG Level Sense -7 - +7
42 3 00 00 00 - 00 01 7F Initial Level
43 3 00 00 00 - 00 00 01 EGmode
44 3 00 00 00 - 00 00 7F AR/IHR
45 3 00 00 00 - 00 00 7F D1R
46 3 00 00 00 - 00 01 7F D1L
47 3 00 00 00 - 00 00 7F D2R
48 3 00 00 00 - 00 01 7F D2L
49 3 00 00 00 - 00 00 7F D3R
4A 3 00 00 00 - 00 01 7F D3L
4B 3 00 00 00 - 00 00 01 RR1mode
4C 3 00 00 00 - 00 00 7F Release1 Rate
4D 3 00 00 00 - 00 01 7F R1L
4E 3 00 00 00 - 00 00 7F Release2 Rate
4F 3 00 00 00 - 00 00 7F Level Scaling Break Point 1
50 3 00 00 00 - 00 00 7F Level Scaling Break Point 2
51 3 00 00 00 - 00 00 7F Level Scaling Break Point 3
52 3 00 00 00 - 00 00 7F Level Scaling Break Point 4
53 3 00 00 00 - 00 01 7F Level Scaling Offset 1
54 3 00 00 00 - 00 01 7F Level Scaling Offset 2
55 3 00 00 00 - 00 01 7F Level Scaling Offset 3
56 3 00 00 00 - 00 01 7F Level Scaling Offset 4
57 3 00 00 00 - 00 00 7F Level Scaling Sense
58 3 00 00 00 - 00 00 7F I.Touch Level Sense
59 3 00 00 00 - 00 00 0E I.Touch->DL Sense -7 - +7
5A 3 00 00 00 - 00 00 0E I.Touch->IHR Sense -7 - +7
5B 3 00 00 00 - 00 00 0E Rate Scaling Sense -7 - +7
5C 3 00 00 00 - 00 00 0E I.Touch->AR Sense -7 - +7
5D 3 00 00 00 - 00 00 0E I.Touch->D1R Sense -7 - +7
5E 3 00 00 00 - 00 00 0E I.Touch->Other Rates Sense -7 - +7
ee = Element No.(00 - 7F: Element1 - Element128)
< Table 6 >
Current Voice / Element Parameter 2
Address Size Data Parameter Description
(H) (H) (H)
70 ee 00 3 00 00 00 - 00 00 01 Cnct
01 3 00 00 00 - 00 00 1F Q
02 3 00 00 00 - 00 01 7F FEG Level init
03 3 00 00 00 - 00 01 7F 1st Fc offset
04 3 00 00 00 - 00 01 7F 2nd Fc offs
05 3 00 00 00 - 00 01 7F 3rd Fc offs
06 3 00 00 00 - 00 01 7F Release1 Fc offs
07 3 00 00 00 - 00 01 7F Release2 Fc offs
08 3 00 00 00 - 00 00 7F FEG Initail Hold Rate
09 3 00 00 00 - 00 00 7F FEG 1st Rate
0A 3 00 00 00 - 00 00 7F FEG 2nd Rate
