Yamaha EX5 EN User Manual
Page 38
38
[24] PHASER2
Controller
01. LFO frequency
0.0Hz~39.70Hz
❍
02. LFO depth
0~127
❍
03. phase shift offset
0~127
04. feedback gain
–63~+63
❍
05. stage
3, 4, 5, 6
❍
06. LFO phase difference
–180deg~+180deg
07 ~ 10. are the same as parameter
✽
.
❍
11. dry / wet balance
D63>W ~ D=W ~ D ❍ [25]~[26]EARLY REF1~2 Controller 01. type S-hall, L-hall, random, reverse, plate, spring 02. room size 0.1~20.0 03. diffusion 0 ~ 10 04. initial delay 0.1ms~200.0ms 05. feedback gain –63~+63 ❍ 06. HPF cutoff frequency 20Hz ~ 8.0kHz ❍ 07. LPF cutoff frequency 1.0kHz~20.0kHz ❍ 08. liveness 0 ~ 10 09. density 0 ~ 3 10. feedback high damp 0.1~1.0 11. dry / wet balance D63>W ~ D=W ~ D ❍ [27] GATE REVERB Controller 01. type type-A, type-B 02 ~ 11. are the same as parameter EARLY REF1 [29]~[31]KARAOKE1~3 Controller 01. delay time 0.1ms~ 400.0ms 02. feedback gain –63~+63 ❍ 03. HPF cutoff frequency 20Hz ~ 8.0kHz ❍ 04. LPF cutoff frequency 1.0kHz~20.0kHz ❍ 05. dry / wet balance D63>W ~ D=W ~ D ❍ [32] AUTO WAH Controller 01. LFO frequency 0.0Hz~39.70Hz ❍ 02. LFO depth 0~127 ❍ 03. cutoff frequency offset 0~127 ❍ 04. resonanse 1~12.0 ❍ 05 ~ 08. are the same as parameter ✽ . ❍ 09. dry / wet balance D63>W ~ D=W ~ D ❍ [33] TOUCH WAH Controller 01. sensitive 0~127 ❍ 02. cutoff frequency offset 0~127 ❍ 03. resonanse 1~12.0 ❍ 04 ~ 07. are the same as parameter ✽ . ❍ 08. dry / wet balance D63>W ~ D=W ~ D ❍ [34] AUTO WAH DISTORTION Controller 01. LFO frequency 0.0Hz~39.70Hz ❍ 02. LFO depth 0~127 ❍ 03. cutoff frequency offset 0~127 ❍ 04. resonanse 1~12.0 ❍ 05 ~ 08. are the same as parameter ✽ . ❍ 09. drive 0~127 ❍ 10. Dist low gain –12dB~+12dB ❍ 11. Dist mid gain –12dB~+12dB ❍ 12. LPF cutoff frequency 1.0kHz~20.0kHz ❍ 13. output level 0~127 ❍ 14. dry / wet balance D63>W ~ D=W ~ D ❍ [36] TOUCH WAH DISTORTION Controller 01. sensitive 0~127 ❍ 02. cutoff frequency offset 0~127 ❍ 03. resonanse 1~12.0 ❍ 04 ~ 07. are the same as parameter ✽ . ❍ 08. drive 0~127 ❍ 09. Dist low gain –12dB~+12dB ❍ 10. Dist mid gain –12dB~+12dB ❍ 11. LPF cutoff frequency 1.0kHz~20.0kHz ❍ 12. output level 0~127 ❍ 13. dry / wet balance D63>W ~ D=W ~ D ❍ [38] DISTORTION Controller 01. drive 0~127 ❍ 02. EQ low frequency 32Hz~2.0kHz ❍ 03. EQ low gain –12dB~+12dB ❍ 04. EQ mid frequency 100Hz~10.0kHz ❍ 05. EQ mid gain –12dB~+12dB ❍ 06. EQ mid Q 1~12.0 ❍ 07. LPF cutoff frequency 1.0kHz~20.0kHz ❍ 08. edge 0~127 ❍ 09. output level 0~127 ❍ 10. dry / wet balance D63>W ~ D=W ~ D ❍ [40] AMP SIMULATOR Controller 01. drive 0~127 ❍ 02. Amp type Off, Stack, Combo,Tube 03. LPF cutoff frequency 1.0kHz~20.0kHz ❍ 04. edge 0~127 ❍ 05. output level 0~127 ❍ 06. dry / wet balance D63>W ~ D=W ~ D ❍ [41] COMPRESSOR Controller 01. attack 1ms~40ms ❍ 02. release 10ms~680ms ❍ 03. threshold –48dB~–6dB ❍ 04. ratio 1~20.0 ❍ 05. output level 0~127 ❍ [42] COMP DISTORTION Controller 01. attack 1ms~40ms ❍ 02. release 10ms~680ms ❍ 03. threshold –48dB~–6dB ❍ 04. ratio 1~20.0 ❍ 05. drive 0~127 ❍ 06. EQ low frequency 32Hz~2.0kHz ❍ 07. EQ low gain –12dB~+12dB ❍ 08. EQ mid frequency 100Hz~10.0kHz ❍ 09. EQ mid gain –12dB~+12dB ❍ 10. EQ mid Q 1~12.0 ❍ 11. LPF cutoff frequency 1.0kHz~20.0kHz ❍ 12. edge 0~127 ❍ 13. output level 0~127 ❍ 14. dry / wet balance D63>W ~ D=W ~ D ❍ [43] EXCITER Controller 01. HPF cutoff frequency 500Hz ~ 16.0kHz ❍ 02. drive 0~127 ❍ 03. mix level 0~127 ❍ [44] NOISE GATE Controller 01. attack 1ms~40ms ❍ 02. release 10ms~680ms ❍ 03. threshold –72dB~–30dB ❍ 04. output level 0~127 ❍ [45] HALL1 ~ [52] PLATE Controller 01. reverb time 0.3s~30.0s 02. diffusion 0~10 03. initial delay 0.1ms~99.3ms 04. HPF cutoff frequency 20Hz~8.0kHz ❍ 05. LPF cutoff frequency 1.0kHz~20.0kHz ❍ 06. reverb delay 0.1ms~99.3ms 07. density 0~4 08. ER / rev balance E63>R ~ E=R ~ E ❍ 09. feedback high damp 0.1~1.0 10. feedback gain –63~+63 ❍ 11. dry / wet balance D63>W ~ D=W ~ D ❍ [53] PITCH CHANGE1 Controller 01. pitch –24~+24 02. initial delay 0.1ms~248.9ms 03. fine1 –50~+50 04. fine2 –50~+50 05. feedback gain –63~+63 ❍ 06. Pan1 L63~C~R63 ❍ 07. output level1 0~127 ❍ 08. Pan2 L63~C~R63 ❍ 09. output level2 0~127 ❍ 10. dry / wet balance D63>W ~ D=W ~ D ❍ [55] ENSEMBLE DETUNE Controller 01. detune –50cent~+50cent 02. initial delay Lch 0.0ms~50.0ms 03. initial delay Rch 0.0ms~50.0ms 04 ~ 07. are the same as parameter ✽ . ❍ 08. dry / wet balance D63>W ~ D=W ~ D ❍ [56] VOICE CANCELAR Controller 01. low adjust 0~26 02. high adjust 0~26 [57] 2BAND EQ Controller 01 ~ 04. are the same as parameter ✽ . ❍ [58] 3BAND EQ Controller 01. EQ low frequency 50Hz~2.0kHz ❍ 02. EQ low gain –12dB~+12dB ❍ 03. EQ mid frequency 100Hz~10.0kHz ❍ 04. EQ mid gain –12dB~+12dB ❍ 05. EQ mid Q 1~12.0 ❍ 06. EQ high frequency 500Hz~16.0kHz ❍ 07. EQ high gain –12dB~+12dB ❍ 08. input mode mono/stereo
[28] REVERSE GATE
[35] AUTO WAH OVERDRIVE
[37] TOUCH WAH OVERDRIVE
[39] OVERDRIVE
[54] PITCH CHANGE2
