background image

Connecting to an External Battery

975-0162-01-01

3-17

To connect the XPower Powerpack to an external battery
using the jump-start cables:

1. Connect the cables to the Jump-Start Cable Port on the

left side of the XPower Powerpack.

2. Connect the red positive (+) clip of the cables to the red

positive (+) terminal of the external battery.

3. Connect the black negative (–) clip of the cables to the

black negative (–) terminal of the external battery.

To disconnect the cables from an external battery and
from the XPower Powerpack:

1. To disconnect the XPower Powerpack from the external

battery when the external battery is discharged or no
longer needed, remove the red positive (+) clip, and then
remove the black negative (–) clip.

2. Remove the cables from the Jump-Start Cable Port.

3. Recharge the XPower Powerpack as soon as possible

after use.

WARNING: Acid spills

Use a sealed, non-spillable battery for indoor use. Common auto
and marine batteries are not suitable for indoor use unless their
fumes are vented outdoors. Common auto and marine batteries
contain acid, which is hazardous if spilled. Wear eye protection
and protective clothing when connecting the XPower Powerpack to
an external battery.

WARNING: Sparking and explosion

Do not remove the cables from the Jump-Start Cable Port when the
positive and negative clamps are connected to the terminals of the
external battery.

CAUTION

Do not recharge the XPower Powerpack when an external battery
is connected. The AC charger may be damaged.
