76
QL Plus Series User Guide
Appendix A
Interface Cables
RS232 Cables
Pin 1
Pin 9
DB-9 Pin
Female Plug
(to P.C.)
8 Pin
Male Plug
(to printer)
(TXD)
(RXD)
(RTS)
(CTS)
(GND)
(DTR)
(DSR)
Shield
(RXD)
(TXD)
(CTS)
(RTS)
(GND)
(DSR)
(DTR)
Shield
3
2
7
8
5
4
6
1
2
3
4
5
7
8
1 4
6
7
3
5
8 2
PC Signals Printer Signals
Part Number ´BL11757-000; 8-Pin DIN to 9-Pin DB PC Cable (For Use With a Personal
Computer)
This part is also available as a coiled cable under Part Number BL15063-1.
PIN 1
6 (DSR)
SHIELD
(GND)
(DTR)
(CTS)
(RTS)
5
4
8
7
DB-9 PIN FEMALE
(PC Signals)
(RXD)
(TXD)
2
3
8 (DTR)
SHIELD
5 (GND)
7 (DSR)
4
3
(RTS)
(CTS)
8 PIN DIN
(Printer Signals)
2
1
(TXD)
(RXD)
1
4
2
5
3
7
8
6
8 Pin Male Plug
(to printer)
PIN 9
USB Cable
Part Number AT17010-1; USB A to USB Mini B Cable
Part Number BL16555-1 (Molded Right Angle DIN Housing to 9-Pin DB)
www.zebra.com/
accessories
