20
QL Plus Series User Guide
All models
2. Load the media:
Loading media from an internal supply. Refer to Figure 7.
• Grasp the media supports where shown and pull them
apart. Insert the roll of media between them, and let the
media supports close. Ensure that the media pulls off the
core in the direction shown in Figure 6. The supports will
adjust themselves to the width of the media, and the me-
dia should be able to spin freely on the supports.
Figure 7: Loading Media (All Models)
Grasp Media Supports
where shown and pull
apart.
Media Roll
Note direction media
pulls off the roll.
