QL Plus Series User Guide
Printhead
Elements
Peeler Bar
Rollers
Located under “EZ-Peel”
Peeler
Platen surface
Avoid using alcohol on
linerless platen surface
Tear Bar
Label
Presence
Sensor
Bar Sensor
Gap
Sensor
Bearing Points
Linerless Platens only
Media Disks,
Inner surfaces on
both sides.
Units with linerless platens
only.
Peeler Bar or
Scraper
Scraper used on units
with linerless platens
only.
Figure 23: Cleaning the QL 320 Plus
