York DM 300 - Manual (Page 25)

262259-YTG-E-1008
Johnson Controls Unitary Products 25
NOTE 1: HACR Type per NEC.
NOTE 1: HACR Type per NEC.
TABLE 17: DM 300 ELECTRICAL DATA STANDARD MOTOR WITHOUT POWERED CONVENIENCE OUTLET
MODEL
(TON-
NAGE)
VOLTAGE
COMPRESSORS
OD FAN
MOTORS
FLA EACH
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
AMPS
HEATER OPTION
MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX.
FUSE/
BRKR
1
SIZE
(AMPS)
RLA
EACH
LRA
EACH
MODEL KW STAGES AMPS
300
(25)
208 41.0 255 4.5 28.0 0.0
None - - - 129.3 150
E18 13.5 1 37.5 129.3 150
E36 27.0 2 74.9 129.3 150
E54 40.6 2 112.7 175.9 200
E72 54.1 2 150.2 185.2 200
230 41.0 255 4.3 26.0 0.0
None - - - 126.9 150
E18 18.0 1 43.3 126.9 150
E36 36.0 2 86.6 140.8 150
E54 54.0 2 129.9 162.4 175
E72 72.0 2 173.2 205.7 225
460 20.5 145 2.2 13.0 0.0
None - - - 63.5 80
E18 18.0 1 21.7 63.5 80
E36 36.0 2 43.3 70.4 80
E54 54.0 2 65.0 81.2 90
E72 72.0 2 86.6 102.9 110
575 17.3 102 1.7 10.0 0.0
None - - - 52.3 60
E18 18.0 1 17.3 52.3 60
E36 36.0 2 34.6 55.8 60
E54 54.0 2 52.0 64.5 70
E72 72.0 2 69.3 81.8 90
TABLE 18: DM 300 ELECTRICAL DATA HIGH STATIC MOTOR WITHOUT POWERED CONVENIENCE OUTLET
MODEL
(TON-
NAGE)
VOLTAGE
COMPRESSORS
OD FAN
MOTORS
FLA EACH
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
AMPS
HEATER OPTION
MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX.
FUSE/
BRKR 1
SIZE
(AMPS)
RLA
EACH
LRA
EACH
MODEL KW STAGES AMPS
300
(25)
208 41.0 255 4.5 38.6 0.0
None - - - 139.9 175
E18 13.5 1 37.5 139.9 175
E36 27.0 2 74.9 141.9 175
E54 40.6 2 112.7 189.1 200
E72 54.1 2 150.2 198.4 225
230 41.0 255 4.3 38.6 0.0
None - - - 139.5 175
E18 18.0 1 43.3 139.5 175
E36 36.0 2 86.6 156.5 175
E54 54.0 2 129.9 178.2 200
E72 72.0 2 173.2 221.5 250
460 20.5 145 2.2 19.3 0.0
None - - - 69.8 90
E18 18.0 1 21.7 69.8 90
E36 36.0 2 43.3 78.3 90
E54 54.0 2 65.0 89.1 100
E72 72.0 2 86.6 110.7 125
575 17.3 102 1.7 15.4 0.0
None - - - 57.7 70
E18 18.0 1 17.3 57.7 70
E36 36.0 2 34.6 62.6 70
E54 54.0 2 52.0 71.2 80
E72 72.0 2 69.3 88.5 100
