Installation
52
975-0004-01-02 Rev D
Reinstalling the Faceplate
To reinstall the faceplace on the
C-Series controller
:
1.
Align faceplate with front of chassis so that screw holes
in the corners line up.
2.
Insert the phillips screws into the screw holes and
tighten.
Figure 2-28 Re-installing the CM Faceplate
Align these screw holes.
Replace the phillips screws
to secure the faceplate.
