ADJUSTING PRINT QUALITY AND SPEED
XEROX DOCUPRINT 96/4635/180 NPS TROUBLESHOOTING GUIDE 7-3
Figure 7-2. Three registration transport roll levers on system
with 7 by 10-inch enablement kit
1 Lever 1: Left - Maximum Pressure setting
2 Lever 2: Right - Maximum Pressure setting
3 Lever 3: Right - Maximum Pressure setting
4. When the print job is complete, return the levers to their normal
position.
5. Close the doors.
Note: Here are a few things to keep in mind when adjusting the
registration transport roll lever:
• Position all levers for the same (either minimum or maximum)
pressure setting. Do not intermix the positions of the levers.
•
Paper greater than 14 inches / 352 mm in any dimension is
considered oversized.
•
Paper heaver than 24 pounds / 90 gsm is considered heavy
weight.
• The following factors may affect the positioning of the paper
levers:
— Machine tolerance
— Paper supplier
— Job type (e.g., duplex).(clockwise).
