CLEARING PAPER MISFEEDS AND JAMS
5-6 XEROX DOCUPRINT 96/4635/180 NPS TROUBLESHOOTING GUIDE
Printer areas
This section provides illustrations of the various areas of the printer
where jams may occur.
The following illustration shows all the jam clearance areas for the
96/4635/180 printer.
The following illustrations show the individual jam clearance areas of
the 96/4635/180 printer.
Area 2
Are
19,
Areas 17, 18
Area 8
Area
6
Areas 2,
3,4,5,7,
9,10
Areas
14,15,
16
Area
13
Areas
11,12
Area
13
Areas
11,12
