EES-1024AF Intelligent Ethernet Switch
5-4 General Setup Using the SMT
Figure 5-5 SMT - IGMP
5.6 Setting the VLAN Mode
Follow the steps to set the VLAN mode.
Step 1. Enter “v” from the main menu to open the VLAN Mode page.
Step 2. Enter one of the two modes at the prompt.
Figure 5-6 SMT - VLAN Mode
5.7 Setting the VLAN for CPU
To set the VLAN for CPU enter “c” from the main menu to open the VLAN for CPU page.
Figure 5-7 SMT - VLAN for CPU
Table 5-2 Fields in VLAN for CPU options
# FIELD DESCRIPTION EXAMPLE
1
Current first
VLAN for CPU Select this option and enter the VLAN ID for the
first CPU. You can choose from ID 1 to 4095.
1
2
Current second
VLAN for CPU Select this option and enter the VLAN ID for the
second CPU. You can choose from ID 1 to 4095.
None
Press “q” to exit this menu.
[Main] [IGMP]
Current state: Enabled
1. Enable
2. Disable
Q. Quit
Select one function (1-2, Q):
[Main] [VLAN Mode]
Current mode: 1
1. VLAN is valid for all packets
2. VLAN is valid for broadcast and multicast packets, not for
unicast packets.
For SmartBits test, this mode will get better throughput.
Q. Quit
Select one function (1-2, Q):
[Main] [VLAN for CPU]
1. Current first VLAN for CPU: VLAN ID 1
2. Current second VLAN for CPU: None
Q. Quit
Select one function (1-2, Q): 1
