Cleaning the Snap Plate
Clean the snap plate to remove label adhesive or a label that has adhered to
the underside of the snap plate.
Refer to Figure 26 .
1. Carefully push the tabs on the snap plate towards the rear of the printer
and gently lift up on the snap plate.
CAUTION: Use care to not bend, twist, or otherwise deform the
tabs!
2. Remove the snap plate from the printer.
3. Clean the snap plate with cleaning solvent and a soft cloth.
Refer to Figure 27 .
4. To reinstall the snap plate, insert the the bottom of the snap plate (with
the notches) into the two slots of the media pathway.
5. Press down on the right and left end of the snap plate (near the tabs)
and lock into place.
