Parallel Data Port
A standard 36-pin parallel connector is available at the rear of the printer for
connection to the data source. Under normal circumstances, data sent from
the printer to the host in response to a “Printer Status Request” command is
sent through the RS-232 serial port. However, if the host has a properly
configured IEEE-1284 parallel port that is recognized by the printer, status
information will be returned through the parallel port. Port selection for
status information is determined each time the printer is turned on.
Parallel Port Interconnections
The following table shows the pin configuration and function of a standard
computer-to-printer parallel cable.
Zebra R-140 User’s Guide 103
36-pin
Connector
Description
1 nStrobe/HostClk
2-9 Data Bits 1-8
10 nACK/PtrClk
11 Busy/PtrBusy
12 PError/ACKDataReq
13 Select/Xflag
14 nAutoFd/HostBusy
15 Not Used
16 & 17 Ground
18 +5V @ 1A
19-30 Ground
31 ninit
32 nFault/NDataAvail
33 & 34 Not Used
35 +5V through a 4.7 K Ω Resistor
36 NSelectIn/1284 active
