41 Operations
Load Media
3/27/07 ZM400/ZM600 User Guide 79695L-001 Rev. A
6.
7. Slide in the media guide until it touches the outer edge of the media.
8. Set the printer to Peel-Off mode. See Select Print Mode on page 64 for instructions.
9. Close the printhead assembly.
10. If the printer is paused (the Pause light is on), press PAUSE to enable printing. Peeling and
liner take-up (if used) begin automatically.
Caution • Use the peel release lever and your right hand to close the peel assembly.
Do not use your left hand to assist in closing. The top edge of the peel roller/assembly
could pinch your fingers.
Close the peel assembly using the peel-off mechanism release lever.
