109 Troubleshooting
Communications Problems
3/27/07 ZM400/ZM600 User Guide 79695L-001 Rev. A
Communications Problems
Table 18 identifies problems with communications, the possible causes, and the recommended
solutions.
Table 18 • Communications Problems
Problem Possible Cause Recommended Solution
A label format was sent to
the printer but was not
recognized. The DATA
light does not flash. The communication
parameters are incorrect. Check the printer driver or software
communications settings (if applicable).
If you are using serial communication, check
the serial port setting in the control panel
menu. See
Set Serial Communications
on page 75 .
If you are using serial communication, make
sure you are using a null modem cable or a null
modem adapter.
Using the control panel controls, check the
protocol setting. It should be set to
NONE . See
Set Protocol on page 77 .
If a driver is used, check the driver
communication settings for your connection.
A label format was sent to
the printer. Several labels
print, then the printer
skips, misplaces, misses, or
distorts the image on the
label. The serial communication
settings are incorrect. Ensure that the flow control settings match.
Check the communication cable length. See
Table 5 on page 19 for requirements.
Check the printer driver or software
communications settings (if applicable).
A label format was sent to
the printer but was not
recognized. The DATA
light flashes but no
printing occurs. The prefix and delimiter
characters set in the printer
do not match the ones in the
label format. Verify the prefix and delimiter characters. See
Set Format Prefix Character on page 78 and
Set Delimiter Character on page 79 for the
requirements.
Incorrect data is being sent
to the printer. Check the communication settings on the
computer. Ensure that they match the printer
settings.
If the problem continues, check the label
format.
