22 Unitary Products Group
345094-YTG-D-0108
Multipliers for determining the performance with other indoor sections.
NOTE: KW RATING IS FOR OUTDOOR AND INDOOR UNITS.
LOW CFM
HEATING PERFORMANCE DATA - LOW CFM 1-STAGE OPERATION
OUTDOOR UNIT MODEL NO. YZH03611
INDOOR COIL MODEL NO. FC/MC62D + MV12D
AIR TEMP.
ENTERING
OUTDOOR
UNIT
AIR TEMP.
ENTERING
INDOOR
COIL
ID CFM
759 809 859
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 31.2 1.8 4.9 31.5 1.8 5.1 31.8 1.8 5.3
70 30.7 2.1 4.2 30.9 2.1 4.4 31.2 2.0 4.5
80 30.2 2.4 3.7 30.4 2.3 3.8 30.5 2.3 3.9
47
60 23.5 1.7 4.1 23.6 1.6 4.2 23.7 1.6 4.4
70 23.1 1.9 3.5 23.1 1.9 3.6 23.2 1.8 3.7
80 22.7 2.2 3.1 22.7 2.1 3.2 22.7 2.0 3.2
40
60 19.4 1.6 3.6 19.5 1.5 3.7 19.6 1.5 3.8
70 19.2 1.8 3.1 19.3 1.8 3.2 19.4 1.7 3.3
80 19.0 2.0 2.7 19.1 2.0 2.8 19.1 2.0 2.9
30
60 14.0 1.5 2.8 14.0 1.4 2.9 14.1 1.4 2.9
70 14.0 1.7 2.4 14.0 1.6 2.5 14.1 1.6 2.6
80 13.9 1.9 2.2 14.0 1.8 2.2 14.0 1.8 2.3
17
60 7.6 1.3 1.7 7.6 1.3 1.7 7.7 1.3 1.8
70 7.8 1.5 1.5 8.0 1.5 1.6 8.2 1.5 1.6
80 8.1 1.7 1.4 8.4 1.7 1.4 8.7 1.7 1.5
10
60 5.3 1.3 1.2 6.0 1.3 1.4 6.7 1.3 1.5
70 6.5 1.5 1.2 7.0 1.5 1.4 7.5 1.5 1.5
80 7.6 1.7 1.3 8.0 1.7 1.4 8.3 1.7 1.5
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil MBH KW COP
AV36 - 1.00 0.98 1.02
AV/SV48 - 1.00 0.97 1.03
MV16C FC/MC43C 1.00 0.97 1.03
MV16C FC/MC48C 1.00 0.97 1.03
MV12D FC/MC48D 1.00 1.00 1.00
MV12D FC/MC60D 1.00 1.00 1.00
Variable Speed
Furnace
Coil T.C. S.C. KW
P(C,V)8*B16 FC/MC/PC43B 1.00 0.97 1.03
P(C,V)8*C16 FC/MC/PC43C 0.96 0.96 1.04
P(C,V)8*C20 FC/MC/PC43C 1.00 0.97 1.03
P(C,V)9*B12 FC/MC/PC43B 1.00 0.97 1.03
P(C,V)9*C16 FC/MC/PC43C 1.00 0.97 1.03
P(C,V)9*C20 FC/MC/PC43C 1.00 0.97 1.03
P(C,V)8*C16 FC/MC/PC48C 0.96 0.97 1.03
P(C,V)8*C20 FC/MC/PC48C 1.00 0.98 1.02
P(C,V)9*C16 FC/MC/PC48C 1.00 0.98 1.02
P(C,V)9*C20 FC/MC/PC48C 1.00 0.97 1.03
P(C,V)9*D20 FC/MC/PC48D 1.00 0.97 1.03
P(C,V)8*C16 FC/PC60C 0.96 0.97 1.03
P(C,V)8*C20 FC/PC60C 1.00 0.98 1.02
P(C,V)9*C16 FC/PC60C 1.00 0.98 1.02
P(C,V)9*C20 FC/PC60C 1.00 0.97 1.03
P(C,V)9*D20 FC/MC/PC60D 1.00 0.97 1.03
P(C,V)8*C20 FC/MC62D 1.00 0.98 1.02
P(C,V)9*C20 FC/MC62D 1.00 0.97 1.03
P(C,V)9*D20 FC/MC62D 1.00 0.97 1.03
P(C,V)8*C16 HC42 0.96 0.97 1.03
P(C,V)8*C20 HC42 1.00 0.98 1.02
P(C,V)9*C16 HC42 1.00 0.98 1.02
P(C,V)9*C20 HC42 1.00 0.97 1.03
