Unitary Products Group 19
345094-YTG-D-0108
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
NOTE: KW RATING IS FOR OUTDOOR AND INDOOR UNITS.
HIGH CFM
COOLING PERFORMANCE DATA - HIGH CFM 2-STAGE OPERATION
OUTDOOR UNIT MODEL NO. YZH06011
INDOOR COIL MODEL NO. FC/MC62D + MV20D
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1718 1818 1918
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 57.5 60.6 60.7 65.4 73.0 58.5 61.3 61.4 66.1 73.4 59.5 62.0 62.0 66.8 73.8
S.C. 57.5 53.3 45.1 44.5 37.1 58.5 54.8 46.3 45.7 37.5 59.5 56.4 47.5 46.9 38.0
K.W. 2.8 2.9 2.9 3.0 3.1 2.8 2.9 2.9 3.0 3.1 2.9 2.9 2.9 3.0 3.1
75
T.C. 55.5 57.9 58.0 62.8 69.7 56.5 58.6 58.6 63.5 70.1 57.4 59.2 59.2 64.1 70.5
S.C. 55.5 52.1 43.9 43.4 35.5 56.5 53.6 45.0 44.5 36.0 57.4 55.2 46.2 45.7 36.6
K.W. 3.3 3.4 3.4 3.5 3.6 3.3 3.4 3.4 3.5 3.6 3.4 3.4 3.4 3.5 3.6
85
T.C. 53.5 55.2 55.3 60.3 66.4 54.4 55.8 55.9 60.8 66.8 55.3 56.4 56.5 61.4 67.2
S.C. 53.5 50.8 42.6 42.3 33.9 54.4 52.4 43.7 43.3 34.5 55.3 53.9 44.9 44.4 35.1
K.W. 3.8 3.8 3.8 4.0 4.1 3.8 3.8 3.9 4.0 4.1 3.8 3.9 3.9 4.0 4.1
95
T.C. 51.5 52.6 52.6 57.7 63.1 52.4 53.1 53.2 58.2 63.5 53.3 53.6 53.7 58.7 63.9
S.C. 51.5 49.6 41.4 41.1 32.4 52.4 51.2 42.5 42.2 33.0 53.3 52.7 43.6 43.2 33.6
K.W. 4.3 4.3 4.3 4.4 4.6 4.3 4.3 4.3 4.5 4.6 4.3 4.3 4.3 4.5 4.6
105
T.C. 48.8 49.1 49.2 54.0 59.4 49.6 49.9 49.7 54.4 59.8 50.4 50.7 50.1 54.7 60.2
S.C. 48.8 47.2 39.8 39.5 30.8 49.6 48.6 40.9 40.5 31.5 50.4 50.1 42.0 41.6 32.1
K.W. 4.9 4.9 4.9 5.0 5.1 4.9 4.9 4.9 5.0 5.1 4.9 4.9 4.9 5.0 5.1
115
T.C. 46.3 45.8 45.9 50.4 55.8 47.0 46.8 46.3 50.6 56.2 47.7 47.8 46.7 50.9 56.5
S.C. 46.3 44.9 38.2 37.9 29.4 47.0 46.2 39.3 38.9 30.0 47.7 47.5 40.4 40.0 30.6
K.W. 5.4 5.4 5.4 5.5 5.6 5.5 5.5 5.5 5.5 5.6 5.5 5.5 5.5 5.5 5.6
125
T.C. 43.7 42.5 42.6 46.8 52.2 44.3 43.7 42.9 46.9 52.5 44.9 44.9 43.2 47.1 52.9
S.C. 43.7 42.5 36.7 36.3 27.9 44.3 43.7 37.8 37.3 28.5 44.9 44.9 38.8 38.4 29.1
K.W. 6.0 6.0 6.0 6.1 6.1 6.0 6.0 6.0 6.1 6.1 6.1 6.1 6.0 6.1 6.2
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
AV/SV60C - 0.99 0.97 0.97
MV20DC FC/MC60D 1.00 0.60 1.18
Variable Speed
Furnace
Coil T.C. S.C. KW
P(C,V)8*C20 FC/PC60C 0.98 0.96 0.96
P(C,V)9*C20 FC/PC60C 0.96 0.94 0.95
P(C,V)9*D20 FC/MC/PC60D 0.95 0.92 0.95
P(C,V)8*C20 FC/MC62D 0.98 0.97 0.97
P(C,V)9*C20 FC/MC62D 0.98 0.95 0.96
P(C,V)9*D20 FC/MC62D 0.96 0.93 0.95
