York YZH024 THRU 060 - Manual (Page 21)

Unitary Products Group 21
345094-YTG-D-0108
Multipliers for determining the performance with other indoor section.
NOTE: KW RATING IS FOR OUTDOOR AND INDOOR UNITS.
HIGH CFM
HEATING PERFORMANCE DATA - HIGH CFM 2-STAGE OPERATION
OUTDOOR UNIT MODEL NO. YZH02411
INDOOR COIL MODEL NO. FC/MC/PC48D + MV12D
AIR TEMP.
ENTERING
OUTDOOR
UNIT
AIR TEMP.
ENTERING
INDOOR
COIL
ID CFM
750 850 950
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 31.6 1.7 5.4 32.0 1.7 5.6 32.4 1.6 5.9
70 30.9 1.9 4.8 31.4 1.8 5.0 31.9 1.8 5.3
80 30.2 2.0 4.4 30.7 2.0 4.6 31.3 1.9 4.8
47
60 26.8 1.6 4.8 27.0 1.6 5.0 27.2 1.5 5.2
70 26.4 1.8 4.3 26.6 1.7 4.5 26.8 1.7 4.7
80 25.9 1.9 3.9 26.1 1.9 4.1 26.3 1.8 4.2
40
60 24.4 1.6 4.5 24.5 1.5 4.7 24.6 1.5 4.9
70 23.9 1.7 4.1 24.1 1.7 4.2 24.3 1.6 4.4
80 23.5 1.9 3.7 23.7 1.8 3.8 23.9 1.8 3.9
30
60 20.7 1.5 4.1 20.9 1.5 4.2 21.0 1.4 4.3
70 20.5 1.6 3.7 20.7 1.6 3.8 20.8 1.6 3.9
80 20.4 1.8 3.3 20.5 1.7 3.4 20.6 1.7 3.5
17
60 16.6 1.4 3.5 16.7 1.4 3.6 16.8 1.3 3.7
70 16.6 1.5 3.2 16.6 1.5 3.3 16.7 1.5 3.3
80 16.5 1.7 2.9 16.6 1.6 3.0 16.6 1.6 3.0
10
60 14.8 1.3 3.2 14.8 1.3 3.3 14.8 1.3 3.4
70 14.7 1.5 2.9 14.7 1.5 3.0 14.8 1.4 3.0
80 14.6 1.6 2.7 14.7 1.6 2.7 14.8 1.6 2.8
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil MBH KW COP
AV36 - 1.00 0.99 1.01
MV12B FC/MC43B 1.00 1.00 1.00
MV12D FC/MC60D 1.00 1.00 1.00
Variable Speed
Furnace
Coil T.C. S.C. KW
P(C,V)9*B12 FC/MC/PC43B 1.00 0.98 1.02
