Xerox 701P47301 - Manual (Page 18)

2 - 8 IPDS User Guide
Installation and Setup
process direction, back side process direction, back side
cross-process direction.
Figure 2-1. Margin adjustments
For example, if the values: 100 0 0 600 are typed in the Stock
Comments field, they represent:
• front side process direction = 100 (1/6 inch or 4.23 mm)
• front side cross-process direction = 0
• back side process direction = 0
• back side cross-process direction = 600 (1 inch or 25.4 mm)
The Stock Library window indicates the presence of Stock
Margins by placing a Stock Comment icon in the Stock Comment
column. If you hover the pointer over the icon, the system will
display the Stock Margins programmed for that stock.
Loading IBM ® AFP Resident Outline Fonts
NOTE: Loading IBM® AFP fonts is optional.
Xerox FreeFlow® Print Server IPDS provides the ability to load
and use printer-resident AFP scalable outline fonts. These fonts
are loaded from the IBM® AFP Font Collection CD, which is
purchased separately. The AFP Font Collection CD label is further
described as Fonts for AIX®, OS/2®, Windows® NT and
Window® 2000, with a part number of LK2T-9269-01.
Back Side Cross
Process Direction
Front Side Cross
Process Direction
Back Side
Process Direction Front Side
Process Direction
