Getting Started
Assigning an IP Address 42
14197L-001 Rev. A ZebraNet
®
10/100 Internal Print Server for ZM400 and ZM600 User Guide 04/19/2007
Assigning an IP Address with DHCP
To assign an IP address using ZebraNet View, complete these steps:
1. From the task bar, select Start > Programs > ZebraNet Utilities > ZebraNet View .
The ZebraNet View dialog opens:
Figure 13 • ZebraNet View
2. Compare the MAC Address on the 10/100 Internal PS network configuration label with
the H/W Address column on the screen to find the 10/100 Internal PS you are working
with.
3. When you locate your 10/100 Internal PS, select it.
4. From the menu bar, select PrintServer > Configuration .
5. If your 10/100 Internal PS does not have an IP address, complete these steps:
• Find your 10/100 Internal PS and right-click.
• In the small dialog that opens, enter an IP Address, click OK .
• The ZebraNet View dialog opens.
Important • On the illustration that follows, take note of the H/W address column and
Serial # column. Compare what you see in ZebraNet View with the network
configuration label you printed out.
Important • If the 10/100 Internal PS does not have an IP address, it shows in the main
screen with an IP of 0.0.0.0. If, after 2 minutes, you do not assign an IP Address, the
10/100 Internal PS defaults to IP Address 192.168.254.254.
