Prestige 645R-A Series User’s Guide
19-2 System Information and Diagnosis
The following table describes the fields present in Menu 24.1 — System Maintenance — Status which
are read-only and meant for diagnostic purposes.
Figure 19-2 Menu 24.1 System Maintenance : Status
The following table describes the fields present in Menu 24.1 — System Maintenance — Status.
Table 19-1 Menu 24.1 System Maintenance : Status
FIELD DESCRIPTION
Node-Lnk This is the node index number and link type. Link types are: PPP, ENET, 1483.
Status This shows the status of the remote node.
TxPkts The number of transmitted packets to this remote node.
RxPkts The number of received packets from this remote node.
Errors The number of error packets on this connection.
Tx B/s This shows the transmission rate in bytes per second.
Rx B/s This shows the receiving rate in bytes per second.
Up Time This is the time this channel has been connected to the current remote node.
Ethernet This shows statistics for the LAN.
Status This shows the current status of the LAN.
Tx Pkts This is the number of transmitted packets to the LAN.
Menu 24.1 - System Maintenance - Status 01:33:24
Sat. Jan. 01, 2000
Node-Lnk Status TxPkts RxPkts Errors Tx B/s Rx B/s Up Time
1-PPP N/A 0 0 0 0 0 0:00:00
2 N/A 0 0 0 0 0 0:00:00
3 N/A 0 0 0 0 0 0:00:00
4 N/A 0 0 0 0 0 0:00:00
5 N/A 0 0 0 0 0 0:00:00
6 N/A 0 0 0 0 0 0:00:00
7 N/A 0 0 0 0 0 0:00:00
8 N/A 0 0 0 0 0 0:00:00
Ethernet: WAN:
Status: 100M/Full Duplex Tx Pkts: 2550 Line Status: Wait for Init
Collisions: 0 Rx Pkts: 2448 Upstream Speed: 0 kbps
CPU Load = 1.46% Downstream Speed: 0 kbps
Press Command:
COMMANDS: 1-Reset Counters ESC-Exit
