Prestige 645R-A Series User’s Guide
16-2 NAT
Figure 16-1 Menu 4 Applying NAT for Internet Access
The following figure shows how you apply NAT to the remote node in menu 11.1.
Step 1. Enter 11 from the main menu.
Step 2. When menu 11 appears, as shown in the following figure, type the number of the remote node
that you want to configure.
Step 3. Move the cursor to the Edit IP/Bridge field, press [SPACE BAR] to select Yes and then press
[ENTER] to bring up Menu 11.3 - Remote Node Network Layer Options.
Menu 4 - Internet Access Setup
ISP's Name= MyISP
Encapsulation= PPPoA
Multiplexing= VC-based
VPI #= 8
VCI #= 35
Service Name= N/A
My Login= username
My Password= ********
NAT= SUA Only
Address Mapping Set= N/A
IP Address Assignment= Dynamic
IP Address= N/A
ENET ENCAP Gateway= N/A
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle
