Prestige 645R-A Series User’s Guide
12-6
Internet
Access
Table 12-2 Menu 4 Internet Access Setup
FIELD DESCRIPTION
EXAMPLE
Multiplexing
Press [
SPACE BAR
] to select the method of multiplexing
used by your ISP. Choices are VC-based or LLC-based.
LLC-based
VPI #
Enter the Virtual Path Identifier (VPI) assigned to you.
8
VCI #
Enter the Virtual Channel Identifier (VCI) assigned to you.
35
Service Name
Only available when PPPoE encapsulation is used. Enter the
name of your PPPoE service provider. This is the same as
Service Name in menu 11.1.
My Login
Configure the My Login and My Password fields for PPPoA
and PPPoE encapsulation only. Enter the login name that your
ISP gives you. If you are using PPPoE encapsulation, then this
field must be of the form
where domain
identifies your PPPoE service name.
N/A
My Password
Enter the password associated with the login name above.
N/A
NAT
Press [
SPACE BAR
] to select None, SUA Only or Full
Feature. Please see the NAT Chapter for more details on the
SUA (Single User Account) feature.
SUA Only
Address Mapping Set When Full Feature is selected in the NAT field, configure
address mapping sets in menu 15.1. Select one of the NAT
server sets (2-10) in menu 15.2 (see the NAT chapter for
details) and type that number here.
When SUA Only is selected in the NAT field, the SMT uses
NAT server set 1 in menu 15.2 (see the NAT chapter for
details).
N/A
IP Address
Assignment
Press the [SPACE BAR] to select Static or Dynamic IP
address assignment.
Dynamic
IP Address
Enter the IP address supplied by your ISP if applicable.
ENET ENCAP
Gateway
Enter the gateway IP address supplied by your ISP when you
are using ENET ENCAP encapsulation.
N/A
When you have completed this menu, press [ENTER] at the prompt “Press ENTER to confirm or ESC to
cancel” to save your configuration or press [ESC] to cancel and go back to the previous screen.
If all your settings are correct your Prestige should connect automatically to the Internet. If the connection
fails, note the error message that you receive on the screen and take the appropriate troubleshooting steps.
