Programming
System Related Commands 52
P1003638-003 TTP 8000 Technical Manual 10/19/2009
System Related Commands
Restarts the printer with a complete reset.
This is the same as power off/on.
Terminates the processing and initializes the control board. The control board is reset to
default-values (same as after power ON). Do not use this command as part of a print data
command string.
Stores a logotype bitmap in the flash PROM. The logotype is printed with the ESC g
commands, see
ESC g n...n5 on page 47 . Also see Logotypes on page 67 .
Erases all logotypes stored in the flash PROM.
Stores the current setting of all parameter values in the setting memory. These parameters are
then used as default parameters. Storing takes approximately 4 seconds. The printer activates
the presenter motor temporarily to indicate that storing is complete.
See also ESC & 5 on page 53 (Set default profile pointer) and ESC P n1 on page 48 (Set
temporary default parameters).
ESC ?
Reset (full)
1B 3F Hex
27 63 Decimal
ESC @
Reset (initialize)
1B 40 Hex
27 64 Decimal
ESC & 1
Load Logotype
1B 26 01 Hex
27 38 1 decimal
Note • If the logo width exceeds the print width, the operation is aborted.
ESC & L
Erase all Logotypes
1B 26 4C Hex
27 38 76 decimal
Note • This command is only executed if at least one logotype has been loaded.
ESC & 4
Store Current Parameter Values
1B 26 04 Hex
27 38 4 decimal
