Product Presentation
Indicators
12
P1003638-003
TTP 8000 Technical Manual
10/19/2009
Indicators
The status indicator flashes in various sequences to indicate specific statuses or warnings.
Figure 3, Printer Exterior, Rear View, on page 11
) has several
functions:
Status-codes are reset:
• When the conditions causing them are removed.
• When the printer is turned off/on.
• When the printhead is lifted and then lowered. On printers without printhead lifted sensor,
remove paper, install again, and press the Feed button to reset.
• When the hardware reset command is received.
ON constantly
The printer is operational.
Flashes rapidly
Indicates error. Hold down the feed-forward button and the number of
flashes will reflect the status-code. See
.
Flash, pauses,
flash
Indicates warnings of non-severe error. The number of flashes reflects
the warning-code. See
.
Table 1 • Status Codes
Number of
Flashes
Status Code Description
1
Paper jam in presenter
2
Cutter cannot return to home position
3
Out of paper
4
Printhead lifted
Note •
Only available on printers with printhead open sensor
installed.
5
Paper wrapped around platen (under head)
6
Temp error, printhead is above 60°C
7
Presenter not rotating
Fast flashes
Checksum error, firmware
Steady light
Wrong firmware type
Off
No firmware is loaded, or wrong firmware checksum
