Specifications
Paper Specification 122
P1003638-003 TTP 8000 Technical Manual 10/19/2009
Preprinting
Figure 29 • Forbidden Print Zones
General To endure the heat developed during printing, the preprint must
meet the requirements applicable for preprinting on paper
intended for laser printing. OCR-blind ink must be used for
preprint on the inner side of the roll.
Ink used for preprinting on the thermal side must be non
abrasive.
The ink must not smear while wound up on the supply roll or
during the printing process.
Print side One side or both sides.
Print area Printing is not allowed in the Black-Mark (1), Presenter (2), and
After Cutter (3) sensor zones. Note that the black mark zone can
be moved if you adjust the sensor position.
Note • Presenter sensors are fitted on printers with presenter, and after cutter sensor on
Compact versions of the printer.
Ba
ck
sid
e
pre
prin
t
Ba
ck
sid
e
pre
prin
t
10mm wide
zones No-Printing
68 mm 82 mm
