This moves to 2nd level screens under “Hardware Setup.” In these screens, the user may make
changes to the unit setup. NOTE: If local control is disabled, then changes to current settings,
channel entry/selection, and audio settings are not allowed, and their screens will not be shown.

B.4.1 Current

Settings

Tunes unit to a new channel setting per user input. Equivalent to a PERM terminal command.

C U R R E N T

S E T T I N G S :

P r e s s

< S E L E C T >

Moves user to 3rd level screens under “Current Settings.”

P O R T : n

R A T E : d d . d d d

P R O G : p p p p p

PORT: n is the ASI input port, 1 or 2,
RATE: ddddd.dd is the input data rate, and
PROG: ppppp is the program number (5 digits).

S A V E :

< E N T E R >

C A N C E L :

< S E L E C T >

saves the new setting and returns to 2nd level screens under “HARDWARE SETUP.”
, then the xx field flashes. Up/down arrows may select a new value. Pressing
tunes the unit to the new channel settings in that Table entry.

B.4.3 Edit

Channel

Edits an entry in the

SETTINGS TABLE

. Equivalent to ADDS and DELS terminal commands.

E D I T

C H A N N E L :

x x

EDIT CHANNEL: xx is a Settings Table entry number. If you press
