Page 8
ViewSonic PJ700
5
E
N
G
L
I
S
H
Connecting Input and Output Devices
Use Figure 3 below as a guide when connecting input and output devices to the ViewSonic PJ700
projector.
The lines in the figure below demonstrate how various input devices can be connected to the
ViewSonic PJ700 projector. For specific connection instructions, refer to the user guide for your
input device.
Figure 3: System Setup
Air Vent
(exhaust)
Remote control
sensor
Rear foot
adjustor
RGB IN 1
RGB IN 2
CONTROL
RGB OUT
USB
Audio IN 1
Audio IN 2
Audio OUT
S-Video
Video IN
Audio IN L
Audio IN R
Notebook
Computer
Desktop
Computer
Audio speakers
VCR
S-Video VCR
(with built-in amplifier)
