Front and Rear View
1. Volume/Squelch Control
2. VFO/Select
Channel/Frequency Control
3. Scan Key (SCAN)
4. Air Service Search Key (AIR)
5. Display
6. Resume Key (
)
7. Hold/Up/Manual Key (
▲/HOLD)
8. Numeric Keypad
9. Menu/Back Key (MENU)
RSM
4
CHAN/FREQ
VFO/SELECT PUSH
SCAN
AIR
SRCH
MENU
VOL SQL
HOLD
LIMIT
RVRS
L/O PRI TRNFR
MUTE
MANUAL
BACK
MODE
UBC785XLT 1000
CHANNEL
RSM
1 2 3
4 5 6
7 8
0
9
E
1-100
301-400
601-700
101-200
401-500
701-800
901-1000
201-300
501-600
801-900
SELECT
1
3 4 5 6 7 8
9 10 11 12 13 14 15 16 17
2
33. Antenna Connector
34. Tape Recorder Output Jack 35. External Speaker Jack
36. DC Power Jack
37. Remote Control Terminal
33 34 35 36 37
10. Search Key (SRCH)
11. Limit/Down Key (LIMIT/
▼)
12. Reverse Key (RVRS)
13. Decimal Key
( )
14. Lockout Key (L/O)
15. Priority Key (PRI)
16. Transfer/Mute Key (TRNFR)
17. Enter/Select Key (E)
