User’s Manual 8-19
Optional Devices
4. With the connector connected, lower the hard disk drive down to the
storage position.
Figure 8-20 Installing the hard disk drive pack
5. Seat the cover and press down until the latches click into place.
6. Secure the cover with two screws.
7. Turn your computer over.
Ultra Slim Bay HDD Adaptor
You can increase your computer’s data storage capacity by installing an
additional 80.0 billion bytes (74.53 GB) and 100.0 billion bytes (93.16 GB)
hard disk drive in the Ultra Slim Bay.
To install a hard disk drive in the Ultra Slim Bay HDD adaptor follow the
steps below.
1. Slide the lock to the unlock position and open the lid.
Figure 8-21 Opening the lid
Plastic tab
Hard disk drive
pack
Connector
Lid
Lock
