43
The Log Server
Configure (continued)
Events
When you open the Add function the following dialog box will
appear:
Descriptions of the fields in this dialog box are shown in the table below:
Field Description
Address This can either be the IP address of the B051-000 or its DNS name (if the network administrator has assigned it a DNS name).
This value must be entered into the ANMS settings screen for the B051-000 to communicate with the Log Server.
Port Key in the port number that was specified for the B051-000 in the ANMS settings screen. If this differs from the port entered in
the ANMS settings screen, the Log Server will not be able to communicate with the B051-000.
Description This field is provided so that you can enter in additional information that will help differentiate this B051-000 from the rest of
the B051-000 units the Log Server is recording information for.
Limit This specifies the number of days that an event is kept in the Log Server’s database before it can be deleted. To remove all
events that have passed the expiration date set in this field, use the Maintenance function in the Events menu.
Edit
Select the Edit function when you need to change the information for an existing B051-000. To edit an existing B051-000, simply select it from
the list and open the Edit function from the Configure drop-down menu. A dialog box will appear that shows the exact information that was
entered for the B051-000 when it was added using the Add function. Edit this information and click OK.
Delete
To delete a B051-000, simply select it from the list and open the Delete function. A dialog box will appear which will display the B051-000’s
information and ask you to click OK to delete it. If you want to remove it from the Log Server, click OK.
The Events Menu consists of two items; Search and Maintenance.
Search
Search allows you to search for events containing specific words or
strings. When you access this function, a screen similar to the one
below appears:
