Tripp Lite B051-000 IP - Manual (Page 4)

4
Introduction
Features
System Requirements
Video
• Provides IP Access to KVM switches or servers that do not have built-in IP functionality.
• Virtual media via USB 2.0 data transmission.
• Precision mouse-pointer syncing ability for USB mice.
• Up to 64 user accounts.
• Up to 32 concurrent user logins for single-bus sharing.
• Message board feature allows users to communicate with each other, and allows a user to take exclusive control of the KVM switch.
• Supports RADIUS, LDAPS and MS Active Directory.
• Export/import user account and configuration settings directly to the B051-000 IP Remote Access Unit.
• Access a KVM switch or server via your web browser using Windows or Java based applications.
• Supports non-browser access via Windows GUI or Java Client software.
• Supports TCP/IP, HTTP, HTTPS, UDP, DHCP, SSL, ARP, DNS, ICMP, CHAP, PPP, 10Base-T and 100Base-T.
• Superior video resolution: up to 1600 x 1200 @ 60Hz; 24-bit color depth for remote sessions.
• Optimize bandwidth using grayscale and other video quality settings.
• PPP mode (modem) dialup support for out-of-band, and low bandwidth operation.
• Allows for full-screen or sizable remote desktop window.
• In full-screen mode the remote desktop display scales to user’s monitor display size.
• Advanced security features include password protection and advanced encryption technologies.
• Secure 128-bit SSL encryption.
• Enable/disable browser operation.
• Event logging.
• Remote firmware upgrading.
• It is recommended that the computers used to access the B051-000 IP Remote Access Unit have at least a Pentium III, 1GHz processor, and
that the screen resolution is set to 1024 x 768.
• Browsers must support 128-bit data encryption.
• It is recommended that the user have an internet connection speed of at least 128 kbps.
• In order to access the Windows Client link, your browser must support ActiveX.
• You must be running Sun’s Java Runtime Environment (JRE) 6, Update 3 or higher in order to access the browser-based Java Applet and AP
Java Client.
• Microsoft Jet OLEDB 4.0 or higher driver must be installed to access the Log Server.
Only the following non-interlaced video signals are supported:
Resolution Refresh Rates
640 x 480 60, 72, 75, 85, 90, 100, 120
720 x 400 70
800 x 600 56, 60, 72, 75, 85, 90, 100, 120
1024 x 768 60, 70, 75, 85, 90, 100
1152 x 864 60, 70, 75, 85
1280 x 1024 60, 70, 75, 85
1600 x 1200 60
