The Grand Tour
Electronic Telephone Diagram
Strata DK Electronic Telephone 5/00
5
Flexible Buttons
All flexible buttons must be programmed for your telephone in system programming
and vary for individual telephones. If a button does not appear on your display or
telephone keystrip label, see your System Administrator for button assignments.
Line Buttons
You may have buttons designated as
/LQH
and/or
3/
which enable you to directly
access outside Central Office (CO) lines.
3/
enables you to access available CO Lines
from a group of lines appearing under one button.
If your telephone does not have a
/LQH
or
3/
button, and you want to access outside
CO lines, you can use access codes. For a listing of these codes, see
Directory Number [DN] Buttons
The [DN] buttons consist of: [PDNs], [SDNs], and [PhDNs]. They are used to make or
answer a call and are known as your extension or intercom number. You can have
multiple [DN] buttons on your telephone (see
), including [DNs]
belonging to another [SDNs].
Incoming calls ring your telephone [PDNs] from the top down. For example,
incoming calls to Station 10 [PDNs] first ring the “10-1” button, then “10-2,” and
finally “10-3.” Your station is considered busy only when all of the [PDNs] are being
used by your telephone or other telephones and/or when your telephone is on a call on
any type of CO Line or [DN].
If you have an LCD telephone, you can find out the actual
[DN] of a [DN] button by pressing the [DN] you want to
display and dialing
. The number (
210
) displays.
DN = 210
