74
General Backup Screen
The General Backup Screen is used for performing bulk backup of video recorded by all cameras for a selected period or periods of
time to a specified storage location.
1 Hour / Minutes Displays recording data in hourly (24 horizontal columns) and 10 minute (6 vertical cells)
segments. Green cells indicate time with recorded video. Red cells indicate time selected
for backup.
2 Eject CD Ejects the CD from the System.
3 Start Backup Initiates the backup process.
4 Browse Opens a menu for adding backup drives or folders not displayed in the Select Backup
Media Menu.
5 Network Drive Allows browsing to and selecting of a remote network location for backing up video to.
6 Backup Order Allows setting of the order in which drives are used for backing up data to.
7 Select Backup Media Allows selection of drives and folders to back up video to.
8 Include Viewer When checked, copies the Backup Viewer application onto the CD or DVD being used for
backup and sets the disc to auto run the viewer.
9 Fixed HDD When checked, displays all hard drives on the system.
10 Backup Status Displays the size of all video currently selected for backup, the available size of the media
currently selected for backup to, and the dates and times of video currently selected for
backup.
11 Calendar Select a date to back up video from; blue highlights indicate dates with recorded video in
them.
