90
Create a New Remote Connection
1 Import Import previously saved configurations
2 Export Export selected configurations
3 User Name Enter the login username.
4 Password Enter the login password.
5 OK Button Click to exit window without connecting
6 Connect Connects the Surveillix Remote Client to the Server.
7 Information Displays the Site Type and IP Address of selected DVR
8 Site Displays a list of pre-configured sites.
9 New Creates a new site to connect to.
10 Modify Used to modify settings of a site selected from the list.
11 Delete Deletes the selected site
12 Delete All Deletes all listed sites.
1. Select Start > Programs > Surveillix > Remote > Surveillix Remote Center. The Surveillix Remote Software opens and the Local
Connection Window opens.
2. Click New to open the Site Info window.
3. Select the Site Type and enter a Site Name. The Site Name will be the name displayed inside the connection box to help
identify the unit.
4. Enter the IP Address of the DVR server. By default the DVR unit is set to connect using DHCP.
5. Enter the Center Port. This setting is specified on the server.
6. Click OK.
7. Click on the newly created connection and enter the login username and password. (case sensitive)
8. Click Connect.
