21
DISPLAY SCREEN
Each time the IPR is started, the program defaults to the Display screen. The following diagram outlines the buttons and features used
on the Display screen. You should become familiar with these options as this is the screen that will be displayed the majority of the
time.
1 Search Opens the Video Search Display.
2 Backup Displays the Backup Center Window.
3 PTZ Opens the Pan / Tilt / Zoom Controller
4 Setup Displays Setup Menu, from which all customizable settings can be edited.
5 Login Allows you to login as a different user.
6 Exit Displays several options, including Shut Down, Restart, and Restart in Windows Mode.
7 Current User Displays the name of the user currently logged onto the IPR.
8 Remote Client Status Displays users connected remotely to the IPR unit.
9 Screen Division Buttons Allows the view of one or more sets of cameras at a time. They are organized in several
different groups such as 1x1, 4x4, and 8x8.
10 Date/Time Displays current date and time. This date and time is stamped onto the recorded video
and is displayed whenever the video is played back.
