33
MOTION SETUP
The IPR unit allows the user to adjust several different Motion Settings and create motion detection areas.
1 Beep on Detect When motion is detected an alarm sounds.
2 Full Screen Pop-Up When motion is detected, the camera displays in full screen mode.
3 Clear Clears all Motion Regions on the selected camera.
4 Apply to all Channels Applies the current motion regions to all camera channels
5 Sensitivity Adjusts the sensitivity within the designated Motion Area.
6 Pre Alarm Adjusts the amount of seconds recorded before an alarm event.
7 Post Alarm (Motion) Adjusts the amount of seconds recorded after a Motion alarm event.
8 Post Alarm (Sensor) Adjusts the amount of seconds recorded after a Sensor alarm event.
10 Regular Interval Recording Select to enable recording at the interval specified in the time box.
