Group Configuration interface
Rapid Spanning Tree
The Rapid Spanning Tree Protocol (RSTP) is an evolution of the Spanning Tree Protocol
and provides for faster spanning tree convergence after a topology change. The system
also supports STP and the system will auto detect the connected device that is running
STP or RSTP protocol.
RSTP - System Configuration
User can view spanning tree information about the Root Bridge
User can modify RSTP state. After modification, click Apply button
RSTP mode: user must enable or disable RSTP function before configure the
related parameters
Priority (0-61440): a value used to identify the root bridge. The bridge with the
lowest value has the highest priority and is selected as the root. If the value
changes, user must reboot the switch. The value must be multiple of 4096
according to the protocol standard rule
