Mounting Installation
DIN-Rail Mounting
The DIN-Rail is screwed on the industrial switch when out of factory. If the DIN-Rail is
not screwed on the industrial switch, please see the following figure to screw the
DIN-Rail on the switch. Follow the below steps to hang the industrial switch.
Step 1: Use the screws to screw on the DIN-Rail on the industrial switch.
Step 2: To remove the DIN-Rail, reverse step 1.
