Hardware Installation
In this paragraph, we will describe how to install the 4 10/100/1000T + 4 SFP Industrial Switch
and the installation points for the attention.
Installation Steps
1. Unpacked the Industrial switch packing.
2. Check the DIN-Rail is screwed on the Industrial switch. If the DIN-Rail is not screwed on
the Industrial switch. Please refer to DIN-Rail Mounting section for DIN-Rail installation.
If you want to wall mount the Industrial switch, then please refer to Wall Mount Plate
Mounting section for wall mount plate installation.
3. To hang the Industrial switch on the DIN-Rail track or wall, please refer to the Mounting
Installation section.
4. Power on the Industrial switch. How to wire the power; please refer to the Wiring the
Power Inputs section. The power LED on the Industrial switch will light up. Please refer
to the LED Indicators section for meaning of LED lights.
5. Prepare the twisted-pair, straight through Category 5e/above cable for Ethernet
connection and SFP transceiver with LC cable for fiber connection.
6. Insert one side of Category 5e or above cables into the Industrial switch Ethernet port
(RJ-45 port) and another side of category 5e or above cables to the network devices’
Ethernet port (RJ-45 port), ex: switch, PC or Server. The UTP port (RJ-45) LED on the
Industrial switch will light up when the cable connected with the network device. Please
refer to the LED Indicators section for LED light meaning.
Note Be sure the connected network devices support MDI/MDI-X. If it does not
support, then use the crossover category 5e/above cable.
7. As for the SFP (mini-GBIC) port, please refer to the Cabling segment.
8. When all connections are all set and LED lights all show in normal, the installation is
complete.
