TFTP restore configuration page to restore the EEPROM value.
1. TFTP Server IP Address: fill in the TFTP server IP
2. Backup File Name: fill the file name
3. Click Apply .
Backup Configuration interface
System Event Log – Syslog Configuration
Configuring the system event mode that want to be collected and system log server IP.
1. Syslog Client Mode: select the system log mode – client only, server only, or both
S/C.
2. System Log Server IP Address: assigned the system log server IP.
3. Click Reload to refresh the events log.
4. Click Clear to clear all current events log.
5. After configuring, Click Apply .
