Olympus SZX10 User Manual
Page 3
SZX10
CONTENTS
IMPORTANT
— Be sure to read this section for safe use of the equipment. —
1
NOMENCLATURE
2
CONTROLS
3
SUMMARY OF OBSERVATION PROCEDURE
4
USING THE CONTROLS
4-1 Base ........................................................................................................................................................................................................................... 7
4-2 Microscope Body and Focusing Assembly ................................................................................................ 7, 8
4-3 Observation Tube ......................................................................................................................................................................... 9-11
4-4 TV Observation and Photomicrography ............................................................................................................ 12
1
Using the Stage Plate
2
Placing the Specimen
1-3
5
TROUBLESHOOTING GUIDE
13
4
5
6
7-12
1
Adjusting the Rotation Tension of the Coarse Focus Adjustment Knob
2
Engaging and Disengaging the Zooming Knob Click Stop Function
3
Adjusting the Aperture Iris Diaphragm
4
Zoom Magnification Indication
1
Adjusting the Interpupillary Distance
2
Adjusting the Diopter (Zoom Parfocal Adjustment)
3
Using the Eye Shades
4
Using the Eyepiece Micrometer Disk
5
Selecting the Light Path of the Trinocular Tube
6
Adjusting the Tilt
1
Selecting the TV Adapter Magnification
2
Mounting the TV Adapter
3
Selecting the TV Camera Light Path
6
SPECIFICATIONS
14,15
7
OBSERVATION MAGNIFICATIONS AND OBSERVATION AREAS
16
